| Prod Model: |
1000-1500mm |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Width: |
1500mm |
| Cooling: |
IBC |
| Winder: |
Double |
| Die Head: |
Fix |
| Up Traction: |
Rotary |
| Type: |
PE Film Blowing Machine |
| Raw Material: |
PE |
| Automation: |
Automatic |
| Computerized: |
Computerized |
| Certification: |
SGS |
Product Description
Condition New
ApplicationFilm
Plastic ProcessedPE
Blow Moulding TypeExtrusion Blow Moulding
AutomaticYes
Place of OriginZhejiang, China (Mainland)
Brand NameAX
Model Number1000-1500mm
Use
Widely used in printing and packaging film, packaging of export products, industrial products, agricultural film and other packaging
The main configuration, technical indicators
1, cylinder rod: φ 75mm, L/D: 28: 1, material: 38CrMoAl, Quenched and tempered, surface nitriding, with special mixing section, good mixing effect, discharging a large amount of;
2, extrusion unit using the ceramic heater heating, forced air cooled automatic temperature regulation, with a durable, accurate, reliable performance;
In 3, a rotary die: Materials for 45 steel forging, mold, mold cavity wall surface hard chromium plating polishing processing, to ensure the high quality of film;
4, digital intelligent temperature control system;
5, extrusion machine reducer adopts the airtight, better reliability of high strength Hardened reducer, has the big bearing capacity, low noise, long life, stable transmission characteristics;
In 6, the machine adopts frequency conversion;
In 7, the blown film raw materials: LDPE, HDPE, LLDPE and other renewable materials;
8, film blowing effective width: 1000 ~ 1500mm;
9: LDPE film, blown film thickness: 0.012mm ~ 0.15mm, 0.01mm ~ 0.1mm: HDPE films;
In 10, the production efficiency: 30 ~ 90kg/h;
11, friction type double volume, maximum winding diameter: 700mm (can be used for the production of film and tube film);
12, pneumatic type reel: φ 73mm;
13, matching the power of three-phase 380V,: 76kw;
In 14, the total weight: 5600kg;
15, equipment installation dimensions (length * width * height): 7100mm × 3200mm × 7200mm.
| Film Width | 1500mm |
| Film Thickness | 0.028-0.2mm |
| Max. Extrusion output | 350KG/H |
| Screw diameter | 60*60*65 |
| L/D | 30:1 |
| The Material of Screw | 38CrMoAl |
| The Material of Cylinder | 38CrMoAl |
| Cylinder heating zone | 4zone |
| Hardened gearbox | 200,200,250 |
| The power of main motor | 30KW*2 37KW |
| Total Power | 200KW |
| Average Power-Consume | 120KW |
| Overall Dimension | 10*6*9m |
Our company located in Rui'an, Zhejiang, where is at the shore of East Sea with beautiful scenery, Ruian Aoxiang Packing Machine Co., Ltd. With a long historical story is a professional manufacturer specialized in producing various packing machines based on advanced technologies. With the help of advanced technology, practical enterprise spirit and full quality management, our company is well known in the whole packing machine market due to our completed equipment and well-deserved reputation.
Our main products cover wrapping film machine, inflation film manufacturing machine, bag machine, printing machine, bubble wrap machine, multifunction coating machine, and completed plastic packing machine.
Our products have been sold to worldwide countries and areas, and enjoy good reputations in the Southeast Asia, the Middle East, Central Asia, Russia, Africa and other countries.
Since our establishment, based on "Credit by Quality, Brand by Credit and Market by Brand" and the tenet of "Competitive Product by Technology, Market Guidance by Service", our company would like to provide our customers with reliable and excellent products through technical innovation and customer satisfaction. We also try our best to make contribution for entire society through high quality and perfect service.
We have rich experience in manufacturing and exporting high packing machines. We have achieved good performance during the past years, sincerely welcome businessmen overseas to establish a long-term cooperation to create beautiful future!
