2015 Hot Sale Heat Curing Furan Resin/Self-Hardening Furan Resin for Foundry Industry
| Price: |
US $ 2800/Ton |
| Trade Terms: |
FOB |
| Min Order: |
10/Ton |
| Pay Type: |
T/T |
| Prod Model: |
FN1#~9# |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Chemical Hardening Sand |
Product Description
No-Bake Furan Resin(FN0-FN7)
Ratio(Weight): Sand:Resin=100:(0.8~2)
Resin:Curing Agent=100:(30~50)
Curing Agent:According to the different temperature can choose the curing agent of different acidity, curing agent can be divided into Several kinds of models such as Spring and Autumn season GH03,Summer GH04, GH05 , and Winter GH08, GH09 etc.
Note: To prevent the explosion,Furan resin and curing agent can't direct contact, If contact with skin, wash immediately with water.
Product Range
Heat curing Furan Resin
No-bake furan resin
Curing agent
Release agent
Binding agent
Sealing clay agent
Mixed alcohols
Casting Steel coating
Deslagging agent
Air Pipe
Fibre filter
Silicone foam ceramic filter
Recarburizing agent
Ferrosilicon
Ferromanganese
Alkaline phenolic resin
Relevant Curing agent
P-Toluenesulfonic acid
Casting Resin Technical Index
| Item | Heat curing Furan Resin | No-bake furan resin | Alkaline phenolic resin |
| Model | F1 | F2 | FN0 | FN Low | FN1 | FN2 | FN3% | FN3 | FN4 | FN5 | FN6 | FN7 | JFZ(lipid harden) | JFC(COsolidify) |
| Appearance | Red brown viscous liquid | Red brown transparent liquid | Deep red brown liquid |
Density
25ºC.g/cm³ | 1.28~1.3 | 1.28~1.3 | 1.12~1.16 | 1.12~1.16 | 1.12~1.16 | 1.12~1.16 | 1.14~1.18 | 1.14~1.18 | 1.14~1.18 | 1.16~1.2 | 1.16~1.2 | 1.16~1.2 | 1.2~1.3 | 1.25~1.35 |
Viscosity
20ºC.mPa.s | 2000 | 2000 | 20 | 20 | 20 | 20 | 30 | 30 | 50 | 50 | 60 | 60 | 50~150 | ≤300 |
| PH Value | 7±0.5 | 7±0.5 | 7±0.5 | 7±0.5 | 7±0.5 | 7±0.5 | 7±0.5 | 7±0.5 | 7±0.5 | 7±0.5 | 7±0.5 | 7±0.5 | ≥12 | ≥12 |
| N%≤ | 13.5 | 11 | 0.3 | 1.5 | 2.0 | 2.5 | 3.0 | 3.5 | 4.5 | 6.0 | 7.0 | 7.5 | free phenol≤0.5% | free phenol≤0.5% |
| Free formaldehyde%≤ | 5 | 4 | 0.05 | 0.05 | 0.05 | 0.05 | 0.05 | 0.05 | 0.3 | 0.3 | 0.3 | 0.3 | 0.1 | 0.1 |
| Normal Temp.Tensile strength Mpa≥ | 3.2 | 3.2 | 2.0 | 2.4 | 2.5 | 2.5 | 2.5 | 2.5 | 2.5 | 2.5 | 2.5 | 2.5 | 1.5 | 1.5 |
| Store period | Half Year | Half Year | 1 Year | 1 Year | 1 Year | 1 Year | 1 Year | 1 Year | 1 Year | 1 Year | 1 Year | 1 Year | 3 Months | 3 Months |
| Total Solid%≥ | 80 | 80 | / | / | / | / | / | / | / | / | / | / | / | / |
| Scope of application | cast iron,cast steel,cast aluminium alloy | Precision cast steel and alloy steel parts | Large steel casting and alloy casting | Steel and alloy steel | Cast steel and large ductile iron castings | Cast Iron and ductile iron casting | Cast Iron and ductile iron casting | Cast Iron and ductile iron casting | Cast Iron and ductile iron casting | Cast Iron and ductile iron casting | Cast iron and copper casting | Cast iron, cast copper, cast aluminum parts | Cast iron, cast steel and alloy casting |
Hangzhou Tianyu Chemicals Co., Ltd. (HTY) is the Top Leading and Largest Manufacturer Specialized in Producing, R&D casting/foundry Furan Resin & Relevant Products in Zhejiang, China. It is located in World Paradise City--Hangzhou, at the south bank of beautiful West Lake, Only 10km away from Hangzhou Xiaoshan International Airport & Shanghai-Hangzhou-Ningbo expressway, also 1km away from Hangzhou-Jinhua-Quzhou expressway. With very convenient transportation and Unique humanities environment.
HTY Company is a strong Modern Garden-like Factory, with the first-class Technology, Scientific Management, Advanced manufacturing technique and equipment, strict testing method, to ensure product quality has reached the international advanced level. "Tianyu products, to your satisfaction forever" is the enterprise aim of HTY, "For Tianyu, we always dedicated" is the spirit of the Tianyu Team, HTY through decades of hard work, adhere to operation principles of Honesty, Quality, Mutual benefit, Friendship, have stood the test in the serious market competition, Won the high trust and long-team cooperation from the renowned leading enterprises and users in casting industry. Our company get rapid development, Brand reputation rising, sales network expanding continuously. Laid a solid foundation for Tianyu Products hot sale in China Market and Towards to All over the world.
HTY Main products are heat cured furan resin, alkaline phenolic resin, self-hardening furan resin, and relevant kinds of curing agents, casting steel coating, casting iron coating, deslagging agent, release agent, ferrosilicon, ferromanganese, adhesive agent, sealing clay strip, mixed alcohol, and etc. With the annual capacity: Cast iron resin of more than 30000 tons, steel casting resin more than 15000 tons, heat curing resin more than 8000 tons, curing agent more than 30000 tons, annual output value hundreds of millions CNY. All Products can meet user requirements, provide supporting services for the clients.
HTY pays great attention to the Products quality, strictly enforce ISO9001 quality management, established a good reputation from Clients by high quality, high stability products. Moreover, Our company will be continues Introduce professional talents, increase technology investment, develop products series, expand production scale. To further consolidate our industry leading position, in order to ensure sustainable development, we will continue make great efforts keep pushing to help China's casting industry to the glory.
