| Prod Model: |
1/2-80" Stainless Steel Weld Neck Flange |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Pressure: |
:T 150lb-2500lb |
| Od: |
1/2-72" |
| THK: |
Sch10-Schxxs |
| Flange Surface: |
FF RF FM Rtj |
| Standard: |
BSW |
| Type: |
Welding Flange |
| Material: |
Stainless Steel |
| Manufacturing Way: |
Forging |
Product Description
(1) Flanges Type: Plate Flange, Flat Flange, Slip on Flange, Welding Neck Flange, Long Welding Neck Flange, Blind Flange, Socket Welding Flange, Thread Flange, Screwed Flange, Lap Joint Flange
(2) Flanges Standards: ANSI Flanges, BS flanges, DIN flanges, EN1092-1 Flanges
(3) Material: Carbon steel flanges ASTM A105, ASTM A350 LF1, LF2 CL1/CL2, LF3 CL1/CL2
ASTM A694 F42, F46, F48, F50, F52, F56, F60, F65, F70
Stainless steel flanges ASTM A182 F304/304L, F316/316L, F316H, F310, F321
F44 (UNS S31254)
Alloy Steel flanges ASTM A182 F1, F5a, F9, F11, F12, F22, F91
(4) Connection Type: Raised Face, Flat Face, Ring Type Joint, Lap-Joint Face, Large Male-Female, Small Male-Female, Large Tongue & Groove, Small Tongue & Groove
(5) Size: 1/2"_24 (DN15_DN600)
(6) Wall Thickness/Pressure Reating: Sch10, Sch20, Sch30, Sch STD, Sch40, Sch60, Sch XS, Sch80, Sch100, Sch120, Sch140 Sch160, Sch XXS, Class 150, 300, 600, 900, 1500, 2000, 3000, 6000, 9000 LBS
(7) Standard: ANSI, ASME, DIN, BS, EN, JIS, GOST
ASME: ANSI B16.9, ANSI B16.28, MSS SP75
DIN: DIN2605/2615JIS: JIS B2313
EN: EN10253-1/2, EN10253-2
| Size | 1/2"-80" |
| material | steel |
| Pressure | 150LB-2500LB |
| Certification | ISO9001,API600,CE0036 |
| Guarantee | 18months |
| Suitable medium | water, oil, gas |
| Design and Manufacture | API600 ,ASME B 16.34, BS1873 |
| Inspection and Test | API598 |
| End flange dimension | ASME B16.5 (for NPS ≤24);AMSE B16.47 series B |
| Socket-weld dimension | ASME B16.11 |
| Face to face and end to end | ASME B 16.10 |
| Pressure-temperature rating | ASME B16.34 |
| Wall thickness dimension | API600 and BS1868 |
Tianjin Golden Hugeline Co., Ltd., located in Tianjin city, is one of the biggest steel groups. Golden Hugeline Group are specialized in producing and exporting all kinds of steel pipe and fittings, flanges, valves in China. Our group is established in 1995 and We have over 15 years' Experience in steel market.
Our group have four branches. The factories of steel pipe and pipe fitting are located in Hebei Province, one flange factory is located in Shanxi Province, and the last one is our sea shipping company in Tianjin. Our main products are pipe fittings, pipes, flanges, valves and so on. We can manufacture according to ANSI/ASTM, JIS, DIN, API, GOST and non-standard. The sizes are 1/2" up to 72" for pipe fittings, 1/2" up to 32" for flanges, 1/2" up to 24" for pipes, 1/2"up to 24" for valves.
Our products have been widely used in many projects. Also we are a good supplier of SGS and have passed ISO, API, TUV, EC and so on. Till now, we have exported to Vietnam, British, Sweden, Japanese, Korea, India, Brazil, Germany, Africa and Middle East counties. We have good reputation from our customers and have long term cooperation with them.
We sincerely hope to cooperate with new and old friends and warmly welcome you to visit our factory.
SKYPE: Huweiyan001 whats APP and wechat: 0086-13752320560
