| Prod Model: |
RTDC-2010016 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Core Steel: |
SKD61 |
| Cavity: |
1X1 |
| Lead Time: |
20-30 Days |
| Mould Base: |
Lkm |
| Material: |
Aluminum |
| Surface Preparation: |
Polishing |
Product Description
Product Description
Specialize in plastic Injection Mold/Hot Runner Mold/Gas Assistant Mold/High Glossy Mold/2K Injection Mold/Over Mold/IML/Stack Mold.
Professional Auto Engine Part Mould Manufacturer over 10 years, certificated by ISO 9001: 2008.
Advantage:
High quality & competitive price & professional skills.
In house strict quality control.
On time delivery.
All mold could be produced automatically
Specification:
Item: Plastic Injection Mold
Part Material: PC/PP/PBT/ABS/PMMA/PU/PE/PVC
Core &Cavity Steel: P20/H13//GS2344/NAK80/ASSAB718HASSAB8407
Mold Base Steel: P20/1050/S50C/
Runner: Hot or Cold
Gate Type: Sprue Gate/Pin Point Gate/Edge Gate/Submarine Gate/Fan Gate/Ring Gate
Cavity No: Single or Multiple.
Mold Base Standard: DME/LKM/HASCO/Etc.
Spare Parts Standard: DME/HASCO/DAIDO/MISUMI/Customized is acceptable.
Mold Life: 30k-1, 000 k
Cycle Time: 10-120 s
Lead Time: 30-45 days
Injection Machine: 50-1200 Ton
Offered Service:
Mold progress report and tooling schedule will be provided weekly.
The first testing sample for buyer's inspection and work out improvement requirements will be provided.
Mold testing video, 2D part drawing and 3D mold design before shipment will be provided.
Payment and Delivery
Payment: TT 50% in advance, Balance before shipment
Delivery Time: 30-45 days
| Specification |
| Design Software: | UG/CAD |
| Analysis Software: | Moldflow |
| Preferred Formats: | STP/IGES/UG |
| Design Time: | 7-15 days |
| Manufacture Time: | 20-30 days |
| Delivery Time: | 30-45 days |
Qingdao Root has engaged approximate 20 professional employees dedicated in mold design. Our design team engages in CAD, CAE and CAM design and formulation using computer software programs. We use CAD programs to generate 2D blueprints and 3D images, use CAE simulation to identify the optimal fabrication pattern, and then generate CAM computer simulation.
We invest in manufacturing equipment from Japanese and European manufacturers, such as Sodick and Makino.
With the advanced equipment and ten years' experience in the industry, Qingdao Root is now offering our manufacturing services to a large and diverse customer base from various industries.
Qingdao Root utilizes the plastic injection molding process to manufacture plastic components of products such as automotive, home appliance, smart phones, portable video game devices, teleconference phone terminals, portable computer memory devices and pachinko machines.
In accordance with our customer's needs, subsequent to design and fabrication of plastic injection molds and mechanical design and manufacturing of plastic components, Qingdao Root provides secondary processes such as spray-painting, printing, hot stamping, ultrasonic welding and assembly of plastic components.
