| Prod Model: |
LY-16 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
Aluminum Windows Press Fabricate Machine, Aluminum Profile Punching Machine (LY-16)
1. Description:
The pressing machine is essential for assembling aluminum windows & doors, applicable to punch aluminum profiles. Each combination dies, assorted with the pressing machine, can complete all punching procedures of window frame and window casement of specification. By changing different dies, the machine can complete processing of windows window frames of different specifications. So it features high safety and small structure. The overall size of all dies is consistent with sealing height. Therefore it is very easy to change dies.
2. Technical Data:
Power Supply 380V/50Hz
Input Power 1.1Kw
Motor Rotational Speed 930r/min
Max. Punching Pressure 30KN
Punching Stroke 17mm
Max. Closing Height 167mm
Workable Size 625*325mm
Die Size 497*200*167mm
Overall Dimensions 730*405*1330mm
Weight 200Kg
3. Payment: Telex Transfer (T/T), 30% be paid after confirming the order and the rest 70% is effected while delivering the goods.
Package: Each PC in wooden cases.
Port of Loading: Qingdao, China
Delivery Time: During 20 days after we receive your first payment.
Trade Mark: SUNNY
4. Contact information:
Mobile number: 0086-13964014791 Lisa
5.Other machine we have:
Since established the company, relying on its mighty real development strenght, advanced management mode, and excellent officers and workers, becomes gradually the professional enterprise with the produces, profession management, sale and after-sales services in a whole. Now our equipments has been exported to many foreign countries. New generation alumi doors and windows that company develops and research concentrates on the industrial development in building materials in Chinese chemistry, can produce the every kind of products with such good functions as elegant appearance, varied colors, soundproof, watertightness and etc. And it can satisfy aluminum and pve doors and windows and insulating glass machine's building requests, improved the Chinese living environment.
