| Prod Model: |
J41H--16 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Dn: |
20-250 |
| Structure: |
Through Way Globe Valve |
| Sealing Form: |
Gland Packings Globe Valve |
| Stem Thread Position: |
Inside Screw Stem Globe Valve |
| Application: |
Bellows Globe Valve |
| Standard: |
JIS |
Product Description
125LB Globe Valve
Specifications
1)Body: Cast iron
2)Bonnet: Cast iron
3)Disc: Cast iron
4)Stem: Brass/Stainless steel
5)Nominal pressure: 125PSI
6)Shell test: 350PSI
7)Seal test: 200PSI
8)Actuator: Manual
9)Suitable medium: Water, oil, vapour etc.
Standard
Design and manufacture: MSS SP-70
Face to face: ANSI B16.10
Flange standard: ANSI B16.10
NPS | 2 | 2.5 | 3 | 4 | 6 | 8 | 10 | 12 |
| DN | 50 | 65 | 80 | 100 | 150 | 200 | 250 | 300 |
| L | 215.9 | 241.3 | 282.45 | 304.8 | 403.35 | 419.1 | 457.2 | 501.6
|
125LB Globe Valve
Specifications
1)Body: Cast iron
2)Bonnet: Cast iron
3)Disc: Cast iron
4)Stem: Brass/Stainless steel
5)Nominal pressure: 125PSI
6)Shell test: 350PSI
7)Seal test: 200PSI
8)Actuator: Manual
9)Suitable medium: Water, oil, vapour etc.
Standard
Design and manufacture: MSS SP-70
Face to face: ANSI B16.10
Flange standard: ANSI B16.10
Pengguang valve factory was founded in 1950 with very professional experience in manufacturing valve.
PG has passed the authentication of ISO9001: 2008, ISO14001: 2004, OHSAS18001: 2007, API 6D, CE, WRAS, KS, EAC.
PG valve manufacture the products with various standards including ANSI, API, AWWA, DIN, BS, JIS, OST, NF and so on.
The material includes HT200, HT250, QT400, QT450, WCA, WCB, WCC, CF3, CF8, CF3M, CF8M, 1Cr5Mo, LCB and etc.
There are 12 kinds and 200 series and 4000 sizes, including gate valve, globe valve, ball valve, butterfly valve, check valve, diaphragm valve, pressure reducing valve, plug valve, steam trap more than 5000 specifications.
We has set up sales branches in the United States, South Korea, Russia, Tunisia, Algeria, Lebanon, Myanmar.
PG has established a sound cooperation relationship with our clients from Europe and the United States, Central Asia, West Asia. PG brand enjoyed a great reputation among our customers.
Welcome your visit to our factory! Hoping our long term cooperation.
