| Prod Model: |
asme |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
Dn15-Dn1500 |
| Package: |
Plywood Case |
| Delivery Time: |
7-30 Days |
| Ome: |
Acceptable |
| Sample: |
Available |
| Standard: |
BSW |
| Type: |
Welding Flange |
| Material: |
Stainless Steel |
| Manufacturing Way: |
Forging |
Product Description
Main Flange Standard List
ITEM | STANDARD |
STNDARD CODE |
PRESSURE RATE |
TYPE | SIZE |
| 1 | American standard | ANSI B16.5 | Class 150,300,600,900,1500,2500 | WN, SW,SO,BL, TH,LWN | 1/2"-24" |
|
ANSI B16.36 | Class 150,300,600,900,1500,2500 | WN, SO, TH | 1/2"-24" |
| AWWA | Class B D E F | RING(HUB) flange | 3"-144" |
| ASEM B16.47 | Class 150,300,600,900 | WN, BL | 26"-60" |
| 2 | British standard | BS4504 | PN6,10,16,25,40 |
WN,SO,PL,BL |
DN10-DN2000 |
3 |
European standard | EN1092 | PN2,5,6,25,40,100,160,250,320,400 | WN,SO,PL,BL | DN10-DN4000 |
| 4 | Japanese standard | JIS B2210 | 5K, 10K, 16K, 30K | SOP(PL,BL), SOH, (SO A,B,C), WN | 10A-1500A |
| 5 | Italy |
UNI 6091-6099
UNI 2280-2286
UNI 2253-2257 |
PN6,25,40,100,160,250,320,400 | BL,WN,PL,SO | DN15-500 |
| 6 | Germany | DIN | PN2,5,6,10,16,25,40,64,100,160 | SO,BL,PL,WN,LOOSE,TH | DN10-4000 |
Material: Carbon steel: ASTM A105,A350 LF2, A694 etc.
Stainless steel: ASTM A182 F304 , 304L,,F304L,F316,316L , AISI 304 , AISI 321etc.
Alloy steel: ASTM A182 A182 F12,F11,F22,F5,F9,F91etc.
Thank you for visiting.
We are looking forward your cooperation sincerely!!!
CONTACT US
Tel: 0086-18734903979
New century machinery Co., Ltd is a professional manufacturer in producing forged flanges and forgings. Established in 2002, after more than 10 years'
Development, now we have nearly 260 employees and 40, 000 square meters, over 200 sets of equipment for forging and machining. The annual
Capacity is 12, 000 tons. We also have obtained certificates of ISO 9001: 2008, TUV/PED, etc.
The flange sizes range from 1/2" to 170". The main standards are ASME B16.5, B16.47, AWWA, DIN, BS, KS, JIS, EN10921, AS2129, etc. We also can
Manufacture various kinds of special flange and forging parts according to customer's drawings or samplesThe main materials include ASTMA105, A350LF2, P245GH, A694F70, A182F11, A182F304 and F316L, etc.
Our products have been exported to South Korea, Japan, Italy, Turkey, Germany, America, Denmark ^, and gotten good reputation for good quality, fair price
And reliable after-service.
Sincerely, you are welcome to visit our company.
