| Prod Model: |
LB-XF |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Airflow: |
2000-32000m3/H |
Product Description
LB-XF cyclone dust collector *Function characteristics: The preprocessor is cyclone dust removal device. Reasonable design;Simple structure;Adopting axial into type;Uniform air distribution, cyclone cylinder external spiral line bypass separation chamber, dust tangent air into a cylinder spiraling flow, along the wall and bypass the separation chamber downward movement, due to centrifugal force role will dust separation, used to remove larger dry density of fibrous dust, dust removal efficiency can reach 85-95%. **Suitable application: Suitable for smelting, casting, sand blasting, building materials and refractory materials and other industries, can also be used for the coarse material level dust collection and dust removal system.
**Technical parameters: | Model | Airflowm3/h | Specification(Diameter*H)mm |
| LB-XF2500 | 2000-3000 | φ700*2600mm |
| LB-XF4000 | 3001-5000 | φ800*2800mm |
| LB-XF7000 | 5001-8000 | φ900*3000mm |
| LB-XF10000 | 8001-12000 | φ1000*3200mm |
| LB-XF13000 | 12001-15000 | φ1100*3300mm |
| LB-XF17000 | 15001-20000 | φ1200*3500mm |
| LB-XF22000 | 20001-25000 | φ1200*3700mm |
| LB-XF30000 | 25001-32000 | φ1300*4000mm |
Company Information:
Qingdao Loobo Environmental Protection Technology Co.,Ltd is one of the biggest enviromental protection products manufacturer, located in Qingdao city of china,specialized in alll kinds of portable fume extractor, downdraft benches(grinding dust removal worktable), central fume purification system, flexible suction arm,etc.
We have more than ten years export experience ,all of our products with the ISO9001 and CE certification, the quality can be guaranteed.
We have our own R&D department , have a variety of style range to meet any of your requirments and had established the economies of scale, so can dilivery fast and provide can beat your competitor's price.
