| Prod Model: |
8.7kgs |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Sand Casting: |
All Sorts of Size |
| Type: |
Clay Dry Sand |
| Material: |
Ductile Iron |
Product Description
Quick Details
| Place of Origin: | Hebei, China | Brand Name: | DSIE | Model Number: | AS PER DRAWINGS |
| Application: | MACHINERY | Material: | Iron | Dimensions: | AS PER DRAWINGS |
| Material:: | Ductile iron,grey iron, cast steel, | Tech.-method:: | Sand cast, | Weight:: | 0.1 - 40000 Kg |
| Standards:: | AISI,DIN,ASTM,BS,EN,NF,JIS,ISO | Investment casting: | Lost wax casting | Die cast aluminium: | Aluminium die casting |
| Heat treatment:: | Available | Pattern & mold:: | Metal pattern, glass steel pattern and wooden pattern | Surface:: | Shot-blasting, painting, plating and polishing |
| Process:: | Automatic moulding and handle |
Packaging & Delivery
| Packaging Details: | Plywood case or As per customers' requirements |
| Delivery Detail: | Plywood case or As per customers' requirements |
Specifications
1.Material:Ductile iron,grey iron,steel castings
2.Process:Sand cast,
3.Standard:ASTM,DIN
We can supply all kinds of ductile iron, grey iron with machining such as electromotor parts, valves parts, pump parts, vehicle parts, marine parts and other machinery parts, materials and technical methods are as follows:
Item | Description | Material | Technical Process |
1 | Ductile iron castings | ASTM A 536-Gr.60-40-18,65-45-12,80-55-06,80-60-03; DIN-GGG40,GGG50,GGG60,GGG70; JIS-FCD40,FCD50,FCD60,FCD70; BS-Gr370-17,Gr420-12,Gr500-7,Gr600-3,Gr700-2; NF-FGS370-12,FGS400-12,FGS500-7,FGS600-3,FGS700-2; | Green-sand moulding Resin-sand moulding Lost foam cast Shell-core cast Electric-furnace smelting |
2 | Grey iron castings | ASTM A48-No.20,25,30,35,40,45,50; ASTM A126-Class A, Class B, Class C; DIN-GG10,GG15,GG20,GG25,GG30,GG35; JIS-FC10,FC15,FC20,FC25,FC30,FC35; BS-Grade 150,180,220,260,300,350; NF-FGL150,FGL200,FGL250,FGL300,FGL350; | Green-sand moulding Resin-sand moulding Lost foam cast Shell-core cast Electric-furnace smelting |
| | |
|
We have special engineers and technicians who have much experiences in arranging production and quality controlling to track all orders and delivery time, and carry out products inspection. Our products have been despatched with all certificates such as chemistry element and mechanical property reports, physical characteristic and non-destructive detect reports if necessary ( UT, MT, PT, RT).
We are always ready for supplying any products to oversea customers with excellent quality, timely delivery, reasonable price and circumspect after service. We welcome you to contact me if you would be interested in us and our products.
Baoding JiangdashengyeTrade Co., Ltd is a production and trade in one company, located in Baoding Hi-tech Development District of Baoding city, Hebei province. The company was founded in 2000, covers an area of 30000 square meters. The company is a professional production of sand casting, die casting, investment casting, forging, plastic parts and other kinds of mechanical parts production factory. The enterprise has a advanced casting production line, various specifications of Numerical control lathe, Milling lathe and so on total 35 sets, 5 CNC Machine. All products are exported to American, Europe, Japan, Middle East and other countries.
Products to the maximum extent to meet customer requirements for product quality, has a good reputation in the industry. Our tenet is quality first, customer first for the purpose. The company has the industry's well-known engineer checks, strong technical force, is your trusted partner. Let customers feel at ease the use of our products is our aim. Welcome more new and old customers to establish long-term cooperative relationship with us. Thank you!
