| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Centrifugal Casting Machine |
| Usage: |
Casting Big Size Brass, Bronze |
| After-Sales Service Provided: |
Engineers Available to Service Machinery Overseas |
Product Description
Bronze/brass pipe used centrifugal casting machine for sale
The machine unit is characterized with simple in structure, high is productivity, low in noise, even in wall thickness, fine and dense in structure, accurate in size, etc. Due to the fact that water-sleeve cooling system is adopted with it. The unit is a complete equipment with international advanced level so it is widely applied in the field of foundry industry.
Main technical parameters of FS-10 centrifugal casting machine
1, Produce casting specification OD dimension of casting is300~900mm, Length of pipe fitting is600~1500mm.
2, Productivity 1~3P/h
3, Cooling water amount 5~10m3/h
4, Electric basic conditions Main circuit AC380V
Auxiliary circuit AC220V
Total loading capacity 55kW
Motor model CT355— 4A
5, The highest linear volocity of the OD of mould 28— 30m/s
6, Total weight 12000kg
Structure of FS-10
FS-10 centrifugal casting machine unit consists of main engine, speed adjusting motor, pouring system, hield, cooling system and electric control cabinet.
Structure and performance
1, Main engine
Use supporting roller structure, four supporting rollers, bearing housing and bottom seat are jointed by T-shape bolts to carry out adjustment and satisfy the mould OD of different specifications.
2, Power system
Use speed adjusting motor ( AC 55kw) to rotate the supporting roller of the main engine through the triangle belt and drive the mould to rotate.
3, Pouring system
Includes pouring trough, bogie and light rail, etc. The pouring trough is knock-down type, the casting bogie can adjust up and down, left and right, and drags the the pouring trough to cast.
4, Shield
Include shield cover and light rail, the shield cover is split type composed of two covers and each cover has four wheels that can be moved by manpower. It shields the mould in the process of pouring to prevent the copper liquid splash and ensure the safety.
5, Cooling system
Include cooler and ball valve, control cooling water by the ball valve to carry out mould cooling.
6, Electric control cabinet
Adopt normal electric control, can adjust the rotate speed of the motor to meet the requirements of different parts and technics.
Our company, founded in 1994, is located in Foshan City, Guangdong Province, in the Pearl River Delta of Nanhai. Our factory covers a building area of 4000 square meters, with all kinds of mechanical processing equipment. Engaged in research and development, we are a professional manufacturer of many kinds of copper rod, brass and lead casting machines, straightening machines, straightening and polishing machines, hydromatic drawlooms, copper and aluminum melting furnaces, temperature holding furnaces and other production equipment. Our company regards environmental protection, energy conservation, and non-pollution as the important index of electric furnace production equipment. We provide price inquiries, technical consultation, training, maintenance and reasonable equipment matching guidance for a new copper factory.
After several years' effort, our factory has developed the following new equipment: Conveyor belt multiple absorbing iron machines, vibration absorbing iron machines, high efficiency low loss combo furnaces, vertical type double acting lead casting machines, automatic peeling machines (no need for heading), automatic combined drawing machines, copper ash cleaning re-blowing production lines, aluminum casting machines, and vacuum casting heading machines for profiled rods (one-time heading).
Our factory always adheres to the principle of "improvement, inspiring innovation, quality first, customer first", and is dedicated to the general customer service with high quality services and low prices. We welcome clients from at home and abroad to come to negotiate business with us. We are willing to work with you.
