| Prod Model: |
AF-C80-300 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Name: |
C Section Purlin Cold Roll Forming Machinery |
| Machine Color: |
as Require |
| Machine Size: |
9m*1.2m*1.4m |
| Machine Weight: |
6tons |
| Size Of Container: |
40gp |
| Control System: |
PLC |
| Cutting Type: |
Hydraulic |
| Driven Type: |
Chain |
| Usage: |
Building |
| Life Long: |
10year |
| Forging Forming Method: |
Mold Forging |
Product Description
C section purlin cold roll forming machinery
Other machine we manufacture
Cold roll forming mahcine, color steel roll forming machine, roof and wall panel machine, decking floor roll forming machine, floor decing forming mahcine, stud and track roll forming machine, Z and C purlin machine, highway guardrail roll forming machine, cable tray machine, and so on.
Working flow:
Decoiler-----feeding----- leveling ------roll forming ------punching------cutting----output table
Machine components:
Roll forming main machine----------------1unit
Manual Uncoiler-------------------------------1unit
Cutting device----------------------------------1unit
Punching device-------------------------------1unit
Control system---------------------------------1unit
Hydraulic station-------------------------------1unit
Output table-------------------------------------1unit
Terms
Payment type: 30% T/T prepaid and balance should be paid before loading
Delivery time: 30days after receving advance payment.
Guarantee period: 18monthes free service/ pay service all the machine life
Installation and training:
If buyers visit our factory and check the machine, we will teach you how to install and use the machine, and also train your workers/technician face to face.
Without visiting, we will send you user manual and video to teach you to install and operate.
If buyer needs our technician to go to your local factory, please arrange board and lodging and other necessary things.
We can produce machine as different profile drawing.
|
Technical description |
Main motor power
|
11KW
|
Hydraulic station power
|
5.5KW
|
Roller station
|
15
|
Yield strength
|
250MPa
|
Diameter of principal axis
|
80mm
|
Shaft material
|
high grade No.45 steel after treatment
|
Material of roller
|
45# steel polished and coated with chrome HRC55-60°
|
Material of blade
|
Cr12 steel after treatment
|
Punching die material
|
Cr12 steel after treatment
|
Processing speed
|
8-15m/min
|
Leveling device
|
5 rollers, 3up,2down for material level
|
Punching type
|
Adopted with 4 pillars hydraulic punches
|
Cutting type
|
Hydraulic cutting after forming
|
Thickness
|
1-3mm
|
Forming speed
|
16-20m/min
|
Controling system
|
PLC Frequency Control System with touch screen
|
We mainly supply high quality roll forming machine. We have achieved good performance up to now, sincerely welcome businessmen overseas to establish a long-term cooperation to create a beautiful tomorrow!
Our factory mainly produce all kinds of roll forming machine, for example, rofo sheet roll forming machine, c purlin roll forming machine, glazed tile roll forming machine, deck floor roll forming machine, sandwich panel production line and so on.
Our factory is established form 2010, up to now, we have sold machines to Canada, Bolivia, South Africa, Dubai, India, Russia and many other countries,
Hope we can cooperate happily
