Product Description
(1) The C&Z shape purlines formed by this machine have excellent anti-bending property and are easy to install. They are widely used as the supporter of roof and wall in large-scale and MID-scale construction, such as factory, warehouse, garage, exhibition center, cinema, theatre, garden and so on.
(2) Producing Process Sketch
The machine mainly consist of Un-coiler, feeding section, leveling, roll forming section, hydraulic punching and post cutting, product stand, PLC control system, and so on.
(3) Technical Parameters
Our C purlin roll forming machine can make many size on the same machine controlled by PLC system
Automatic cutting and punching at any position. Multi order for length and hole distance.
|
Dimension For C-Purlin |
|
Type |
Profile Dimension (mm) |
Distance between
holes (mm) |
|
H |
B1 |
B2 |
C |
T |
|
C80 |
80 |
40 |
40 |
15 |
1.5-3.0 |
adjustable |
|
C100 |
100 |
50 |
40 |
20 |
|
C120 |
120 |
50 |
50 |
20 |
|
C140 |
140 |
50 |
50 |
20 |
|
C160 |
160 |
60 |
60 |
20 |
|
C180 |
180 |
60 |
60 |
20 |
|
C200 |
200 |
60 |
60 |
20 |
|
C220 |
220 |
70 |
60 |
20 |
|
|
|
Max. material strength |
G550 |
|
Forming steps |
16 - 18 |
|
Thickness |
1.5-3.0mm |
|
Cutting tolerance |
Length ± 2mm (length = 5, 000mm) |
|
Control system |
calculation by PLC touch interface display |
|
multi - grouped input |
|
auto length and hole distance calculating |
|
use mm as the length - calculating unit |
|
tolerance revision by touch screen |
|
|
|
Max. roll forming speed |
Max. roll forming speed |
|
Main motor power |
11 - 25 KW |
|
Un-coiler |
1 set (mechanical type) |
|
Machine installation dimension |
13m*1.4m*1.6m |
Cutting and punching
equipment |
Exit shearer: max 9 sets |
|
Holes punching: max 6 sets |
