| Prod Model: |
CF-11 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Package: |
Pallet ,Manmade Wooden Case or as Your Requirement |
| Origine: |
Qingdao |
| Brand: |
Chifine |
| Service: |
OEM and ODM |
| Certificate: |
ISO9001 SGS CE |
| Delivery Time: |
30 Days After Receiving The Payment |
| Tolerance: |
CT7-CT9 |
| Machining Type: |
CNC Tunring Milling Drilling Lathe |
| Heat Treatment: |
Anealing ,Normalizing ,Quenching ,Tempering |
| Process: |
Sand Casting+CNC Turning |
| Type: |
Clay Wet Sand |
| Machining: |
CNC Machining, CNC Turning Milling Drilling |
| Surface Treatment: |
Sand Blast, Powder Coating, Painting, Polishing |
Product Description
Product Description:
1) Material: High Grade Ductile Iron (450-12/500-7/600-3/700-2);
2) Process: Resin sand casting.
3) Applied software for specification drawings: Pro/E, AutoCAD, Solidworks etc.
4) Facility: Electric furnace, cupola furnace, anneal furnace, sand mixing machine, shot blast chamber, various molding machine.
5) Precision machining: CNC, NC lathes, boring machines, milling machines, bench drilling machines, etc.
6) Surface Protection: oiled (rust-proof), electroplating, hot dip galvanizing, painting, powder coating.
7) Products' location: The special designed fittings, widely used in, power station, industrial equipment, vehicles, etc.
tem Name: |
Sand Casting |
Product Description: |
1)Material: Grey Iron, Ductile Iron, Carbon steel, stainless steel, bronze, alloy steel
2)Surface Finish: Zinc/nickel/chrome plating, hot galvanized, painting, polishing, sand blasting
3)Available Service: Lost Wax casting, sand casting, Precision CNC machining
4)Applicable Industry: Pipes and its fittings, Marine, aerospace, electronics, automobile, hydraulic etc |
Company Profile: |
We are able to design and manufacture precision casting, sand casting and precision CNC machining based on customer's drawings/samples. At present, we have advanced equipment and professional technology to promise the best quality.
The pictures shown on the website are for reference only. Any ODM/OEM inquiry will be welcomed. |
Company Advantage: |
1.ISO 9001:2000 certified
2. Strick Chemical composition control
3. Advanced equipment and excellent R&D Team
4. Highly skilled manufacturing process
5. A broad variety of ODM&OEM product range
6. Strict quality Control System |
Practicable File Formats: |
Pro/Engineer, SolidWorks, Unigraphics, Auto CAD, (IGS, STP, STL and X-T) |
Qingdao Chifine Machinery Co., Ltd is One Famous Company in China Which Specialized in Various Metal Casting Products with Over 10 Years Experience Located in Qingdao China. It Covers a Comprehensive Range of Forging, Stamping, Sand Casting, Investment Casting, Die Casting and Machining and Was Widely Used in Agriculture Machinery, Motor Vehicle, Architecture, Railway and Engineering Chifine Has Accumulated Important and Valuable Experience in Design, Manufacturing and Customer Service Over These Years We Will Continue to Integrate Our Technical Superiority, Improve Process and Quality to Increase Market Share and Create More Brilliant Future.
Automative Casting Line:
• Material: Grey iron(GG20-GG35); Ductile iron(GGG40-GGG60);
Malleable cast-iron(GTS35-10/45-06/55-04/65-02, CTW35-04/05/06/07).
• Product Size: 0-1000mm.
• Weight: 0.2kg-100kg
Resin Sand Casting
• Material: Grey iron(GG20-GG35); Ductile iron(GGG40-GGG60);
Malleable cast-iron(GTS35-10/45-06/55-04/65-02, CTW35-04/05/06/07).
Steel casting(ASTM/UNS; DIN; JIS; NF; BS; ISO)
• Product Size: 0-1500mm.
• Weight: 10kg-5000kg
Shell Mould Casting
Shell casting is one of resin sand casting process.
It is suitable for thin-wall casting parts, be free from porosity.
• Material: Grey iron(GG20-GG35); Ductile iron(GGG40-GGG60);
Malleable cast-iron(GTS35-10/45-06/55-04/65-02, CTW35-04/05/06/07).
Steel alloy; Aluminum alloy; Copper alloy.
• Product Size: 0-500mm.
• Weight: 50g-100kg.
• Wall thickness: 4-20mm
Lost Wax Casting
• Advanced wax-injection-machine and tool to ensure accurate wax-patten.
• Stable temperature and humidity environment make the wax-patten no deformation.
• Material:
Carbon steel; Stainless steel; Alloy steel.
Grey iron(GG20-GG35).
Ductile iron(GGG40-GGG60);
Malleable cast-iron
(GTS35-10/45-06/55-04/65-02, CTW35-04/05/06/07).
Aluminum alloy; Copper alloy.
• Casting size: 0-500mm.
• Casting weight: 50g-100kg
Stamping and Forging Line
• Stamping and forging equipment: 16T-300T press machine
• Automatic transport forging line
• Material: Carbon steel; Stainless steel; Alloy steel.
Aluminum alloy; Copper alloy.
Machining Shop
Our machining shop located in Qingdao, using the latest CNC equipment to provide our customer with high quality products.
• Horizontal and Vertical Machining Center
• CNC lathe and normal lathe
• CNC drilling and milling Center
• Other assistant equipment
