| Prod Model: |
GW-HY98 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
Product Description
This is the device converting three phase power current into single phase intermediate frequency current and enabling metal to produce eddy current loss through electromagnetic field induction to achieve heating and melting and is applicable to melting, heating or holding of steel, copper, iron, aluminum, zinc, tin, nickel silver and other ferrous or nonferrous metal and alloy material, as well as heating treatment prior to forging, sintering and tube-bending forming in casting and melting industries.
1. Using a zero-voltage scanning soft-start mode, in any case may at any time to start or stop, will not have impact on power supply.
2. Fast smelting with low production cost; Low-pollution and environment-friendly;
3. A direct effect from the cold furnace melting. Dissolved material will be fully dumped clean. Molten material easy to replace.
4. Power adjustment flexibility. Be able to continuously smooth adjustment. Temperature uniformity can be easily controlled. Oxidation burning less. Metal components evenly.
5. Furnace shell using cast aluminum or steel structure, small footprint; Furnace flip dump convenience, according to the need to use electric, manual, hydraulic tilting furnace and other means.
6. Designed to automatically adjust angle of inverter circuit that can automatically adjust the load impedance match, without adjustment of capacitance compensation and always run the equipment in good working condition; Power supply system diagnostic error function, easy maintenance.
Product Feature
1. Simple installation
2.40 year experience
3...For melting steel, cast iron, stainless steel, copper, aluminum
Product Specification/Models
Type: Induction Furnace
Usage: Melting Furnace
Guarantee: One year
Supply Ability: 1000 Set/Sets per Year
Minimum Order Quantity: 1 Set/Sets
Payment Terms: L/C, T/T, Western Union, cash
Certificate: CE ISO900
We have stocks so we can arrange for the delivery very fast!
We uphold "first quality, first customers, first service"
Sincerely provide service for you!
|
Furnace Capacity |
Rating Power |
Input Voltage |
Input Phase |
Input Current |
Assorted Transformer |
Output Voltage |
Output Frequency |
Melting Time |
Volume |
Weight |
|
10-50KG |
50KW |
380V |
3 |
80A |
60KVA |
750V |
2.5KHZ |
20-60Min |
1.2 m³ |
350KG |
|
100KG |
100KW |
380V |
3 |
160A |
120KVA |
750V |
1KHZ |
20-60Min |
6 m³ |
1500KG |
|
150KG |
100KW |
380V |
3 |
160A |
120KVA |
750V |
1KHZ |
30-70Min |
6.5m³ |
1600KG |
|
200KG |
120KW |
380V |
3 |
192A |
150KVA |
750V |
1KHZ |
30-70Min |
7.5m³ |
1700KG |
|
300KG |
130KW |
380V |
3 |
208A |
150KVA |
750V |
1KHZ |
30-70Min |
8.5m³ |
1800KG |
|
500KG |
250KW |
380V |
3 |
400A |
315KVA |
750V |
1KHZ |
30-70Min |
9.5m³ |
2300KG |
|
600KG |
350KW |
380V |
3 |
560A |
400KVA |
750V |
1KHZ |
40-80Min |
11m³ |
2500KG |
|
750KG |
450KW |
380V |
3 |
720A |
500KVA |
750V |
1KHZ |
40-80Min |
12m³ |
3800KG |
|
1000KG |
600KW |
380V 380V-2 |
3/6 |
960A 480A |
600KVA 800KVA |
750V 1300V |
0.8KHZ |
50-90Min |
13m³ |
4500KG |
|
1250KG |
800KW |
380V 380V-2 |
3/6 |
1280A 640A |
800KVA 1250KVA |
750V 1300V |
0.8KHZ |
50-90Min |
14m³ |
5000KG |
|
1500KG |
1000KW |
380V 380V-2 |
3/6 |
1600A 800A |
1250KVA 1500KVA |
750V 1300V |
0.8KHZ |
50-90Min |
15m³ |
5500KG |
|
2000KG |
1250KW |
660V 380V-2 |
3/6 |
1120A 1000A |
1500KVA 1800KVA |
1300V |
1300V |
50-90Min |
17m³ |
6000KG |
|
3000KG |
1500KW |
660V 380V-2 |
3/6 |
1350A 1200A |
1800KVA 2000KVA |
1300V |
1300V |
60-100Min |
20m³ |
7000KG |
|
5000KG |
2500KW |
1000V 660V-2 |
3/6 |
2000A 1120A |
3000KVA 3500KVA |
1300V |
1300V |
60-100Min |
23m³ |
8500KG |
Foshan Hengyang Furnace Manufacturering Co., Ltd. Was established in 1999, located in Foshan city, where is 30 miles away from Guangzhou Airport.
We are one of the largest leading intermediate frequency furnace manufacturers in China. We have been ISO 9001 and CE certified, achieved the quality management of international practice. Our company had been awarded High Quality Product and Faithful Organization Prizes by our government.
Our main product includes Energy Saving Intermediate Frequency Melting Furnace, Intermediate Frequency Induction Furnace, Metal Furnace, Melting Furnace, Induction Heating Furnace etc. Our Product is widely applicable to melting, warming or insulating of steel, cooper, aluminum, zinc, gold, silver or other metal or alloy, heating treatment before forging, sintering and tube-bending forming, and quenching, tempering or other heating of mechanical parts in casting and melting industries.
With strong design, application and manufacturing capacity, hundreds of mechanical processing equipment, a group of experienced engineering technicians who have been engaged in high and intermediate frequency product design and manufacturing for more than 20 years, we have absorbed domestic and international advanced technologies as well as excellent workmanship and reliability of former products based on years of practice and improvement, have been known for rational design, stable performance, easy operation and attractive price across China and have been widely recognized by customers, and have helped our customers to obtain good production and economic benefits. Our products are exported to Europe, Africa, Russia, India, Malaysia, Bangladesh, Korea, Vietnam, Iran, Bahrain, and other country or region.
We are committed to deliver "turnkey" project covering not only quality and reliable products but also application related products but also application related process, technology and operator training for free f charge. We have separate after-sales department to perform regular follow-up service and reassure customers by directly solving of any problem emerged in practical production.
We always follow the business principle of "faithful and down-to-earth" and take "today' S quality, tomorrow' S market" as our operation philosophy to promote goodwill with quality and win public praise with service in fierce market competition bringing both challenge and opportunity. Let' S build a bright future in a sharing and win-win manner. We welcome regular and new customers visit our premises for negotiation. You will be warmly served!
