Product Description
(1) Color imaging
So far, there are only black and white in the market, i. E. We need to change the five color seven colors to black and white, during the calculation programming, there is an analyze time, make the speed slow. However, our machine sample the signal with color, no matter what color the PET film print, it can imagine directly, so the speed is fast. Now, the technology of our software can reach the Euro-American level, black and white product will be eliminated in the domestic.
(2) Big work bench
It adopts artificial marble, no static, with size as 1200*800mm
(3) High efficiency
With the function of single punching and automotive multi hole continuous punching.
(4)Window
Our touch screen adopts microsoft windows operating system, it can contact to computer.
(5)Suitable for film with any colors
It can match various photographic material, such as infrared: Reflecting infrared, far-infrared, transmission ultraviolet, multi-color reflecting light and transmission white light.
(6)It mainly used in PET basic material punching work with the thick less than 0.35mm.
(7)Punching hole error: Less than 0.015mm; Punching hole speed: 0.5s/hole; Recognize circle diameter: Dia. 1-5mm; Throat depth: 300mm; Max. Punching force: 120kg; Voltage: Single phase 220V;
Work atmosphere pressure at 0.4-0.7mpa.
Aimudi Tech Industry (HK) Co., Ltd. is the professional IMD service team in China; Supply the customers with machines, PET films and technology. So far we have founded the service centers in Shenzhen, Shanghai and Zhongshan.
We have developed series of high-tech products, the most represented products: The best intelligent CNC forming machine in China, high pressure gas static forming machine with the newest technology, CCD imagine auto contraposition punch machine and etc.
We have participated the following projects:
BYD IMD(IML) new item building, ordering 36 set intelligent CNC forming machines;
Haier (QingDao) IMD(IML) new item building, ordering 8 set 1200*600mm forming machine with the bigest area.
Leading Foxconn PC material reforms to PET material, as the technology transformation;
Delux portable computer IMD(IML) new item building, ordering 6set CNC forming machine;
...
Our company introduced PET polyester film from Aquatex Britain, Nakai Group Japan, TOYOBO Japan, Toray Group Japan and also from Korea; So far we can produce more than 100 ton excellent film annually.
Aimudi is in accordance with "Specialized in one profession, leading the brand", collecting all of the advantage resource, credit management, and we expecting the experts from the similar industry to guide and support our work.
