China Cardan Shaft for Machineries

Prod Model:	SWC
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Material:	Steel
Dimension:	Customized
Brand Name:	Wc
Delivery Time:	20 Days
Production Standard:	According to Drawings to Manufacturing
OEM / ODM:	Available
Quality Guarantee:	ISO9001:2008
Surface Finish:	Heat Treatment, Rust Prevention
Application:	Agricultral &Water & Heavy Duty Machines
Place Of Origin:	China
Load:	Drive Shaft
Stiffness & Flexibility:	Flexible Shaft
Axis Shape:	Straight Shaft
Shaft Shape:	Real Axis

Product Description

1.Product specification
1), advance technology
2), high accuracy and closely structure
3), high quality, the best price and good services
4), Strictly quality control by ISO9001: 2008.
5), with R&D Dept, OEM is available
2. About our advantages
1). With 10 years experience and professional OEM / ODM
2). Advance technology and R&D Dept with rich experience
3). Delivery in time
4).Competitive and reasonable price
5). High reputation

3.About our products

Data and Size of SWCZ Series Universal Joint Couplings:

Type	Design Data Item	SWCZ 680	SWZ 700	SWZ 750	SWZ 780	SWZ 800	SWZ 840	SWZ 900	SWZ 920	SWZ 1000	SWZ 1060	SWZ 1100	SWZ 1200
C	L	1540	1600	1840	1920	1920	2120	2280	2280	2380	2480	2500	2720
	M(kg)	3150	3450	4300	4680	5050	6400	8420	8950	10600	12100	13500	16900
D	L	1940	2100	2400	2500	2500	2680	2950	2950	3130	3200	3300	3570
	M(kg)	3220	3530	4500	5400	5800	7470	9980	10500	12300	14500	15800	19500
E	L	3230	3460	3620	4000	4000	4250	4580	4850	4770	4950	5100	5660
	LV	250	250	250	250	250	250	300	300	300	300	300	300
	M(kg)	4880	5400	8000	8450	9070	11800	15900	16500	19900	22000	27500	34800
Tn(kN·m)		1640	1750	2250	2500	2670	3100	3800	4050	5200	6500	6900	9000
TF(kN·m)		980	1050	1350	1500	1600	1860	2280	2430	3120	3900	4140	5400
Β(°)		15	15	15	15	15	15	15	15	15	15	15	15
D		680	700	750	780	800	840	900	920	1000	1060	1100	1200
Df		680	700	750	780	800	840	900	920	1000	1060	1100	1200
D1		635	635	695	725	745	775	835	855	915	980	1015	1100
D2(H9)		550	570	610	640	660	710	740	760	840	840	920	1000
D3		560	560	620	660	660	660	750	750	790	800	850	900
Lm		385	400	480	480	480	530	570	570	595	620	625	680
K		70	70	95	95	95	110	120	120	130	130	130	130
N		24	24	24	24	24	24	24	24	20	20	20	20
D		26	26	31	31	36	38	38	38	50	45	50	58
Flange bolt		M24	M24	M30	M30	M30	M36	M36	M36	M48	M42	M48	M56

(1). Notations:
L=Standard length, or compressed length for designs with length compensation;
LV=Length compensation;
M=Weight;
Tn=Nominal torque(Yield torque 50% over Tn);
TF=Fatigue torque, I. E. Permissible torque as determined according to the fatigue strength
Under reversing loads;
Β=Maximum deflection angle;
(2). Millimeters are used as measurement units except where noted;
(3). Please consult us for customizations regarding length, length compensation and
Flange connections.
(DIN or SAT etc. )

 4. About factory

our factory  specializes in processing and  trading of SWC type cardan shaft ,located in the famous tourist city - Wuxi, China.
Our company has accumulated rich experience in the production and absorbed  foreign advanced technology .we always adhere to the ISO9001 quality system to control the  quality ,production  process from the perspective of the detail specification .we persistent innovation ,optimization of structure .And high quality products have enjoyed high reputation especially in Germany and Middle East ,and have been widely supplied to domestic enterprises.

Welcome to contact us if you are interested in products and want furtherdetails.
Looking farward to cooperating with

FAQ

Q1: What is your lead time?
A1: Within 20 days after receiving payment

Q2: Do you offer OEM service?
A2: Yes. We can manufacture and design any specific product customer required.

Q3: How we do quick response to customer inquiry?
A3: Professional lines, widely supplier sourcing and we will try our best to reply you at first
Time!

Q4: How was your after-sales service?
A4: We have plenty of inventory, all products accessories, ten years supply guarantee!

Q5: I don't know what to choose what types of cardan shaft and how to
Do?
A5: We have a strong design team, to provide you with non - standard custom scheme of
Cardan shaft! Just contact us!
