| Price: | US $ 23kg |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 50kg |
| Pay Type: | L/C,T/T,D/P,Money Gram |
| Prod Model: | gr2 titanium pipe |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Outer Diameter: | 10-104mm |
| Length: | 500-12000mm |
| Material: | Pure Titanium and Titanium Alloy |
| Inside Diameter: | 4-104mm |
| Wall Thickness: | 0.5-9mm |
| Condition: | Annealed |
| Surface: | Acid Pickled or Polished |
| Type: | Titanium Pipes |
| Application: | Medical |
| Technique: | Seamless |
| Grade: | GR2 |
| Shape: | Round |
Titanium Seamless Tube/PipeTitanium Sponge→Compacting Electrodes →Melting →Forging→ Billet→ Extruding→ Rolling→ Straightening→ Seamless Tube
Application:
1.Bicycle and automobile exhaust tubing ,cooling pipe,Electroplating equipment,precision instruments , ring,environmental protection equipment
2.Thermal power engineering:condenser, heat exchanger, engine vane .
3.Vessels:Running pipes, submersible,gas cylinder
4.Oceaneering: evaporator, heat transmitter, exchanger,oil production platform, oil cooler
5.Chemical engineering:Flat plate heat exchanger, flat plate condenser, cooler tower,chloride barrels
6. Aerospace:Engine, fan plate, gas compressor vane, rack, hatch cover, empennage.
| Production Name | titanium tube | ||||||
| Grade | Gr 1 gr2 Gr5 Gr7 Gr9 Gr12 | ||||||
| Size | 8-40*0.5-1.0*4000mm | ||||||
| Standard | ASTM B337 ASTM B338 ASTM B861 ASTM B862 | ||||||
| Feature | High corrosion resistance low density good thermal stability | ||||||
| Packing | Wooden case as outside, plastic bag as inside, or standard export packaging | ||||||
| Min Order | 20kg | ||||||
| Payment terms | L/C T/T | ||||||
| Delivery time | 10_30days according to the quantity and process of the product | ||||||
| Quality And test | Strict test is indispensible, because we must insure our clients get the best product | ||||||
| seamless titanium tube and weld-rolled titanium tube | |||||||
| category | Seamless titanium tube | Weld-rolled | |||||
| OD<15 | OD>15 | OD | |||||
| WT<2.0 | WT>2.0-4.5 | 0.5-0.8 | >0.8-2.0 | ||||
| Length(mm) | 500-4000 | 500-9000 | 500-6000 | 500-800 | 500-5000 | ||
| category | Weld titanium tube | ||||||
| WT 0.5-1.25 | WT > 1.25-2.0 | WT >2.0-2.5 | |||||
| Length(mm) | 500-15000 | 500-6000 | 500-4000 | ||||
| tolerance | |||||||
| OD (mm) | The OD tolerance | The WT tolerance | |||||
| >6-25 | + 0.10 | + 10% | |||||
| >25-38 | + 0.13 | ||||||
| >38-50 | + 0.15 | ||||||
| >50-60 | + 0.18 | ||||||
| >60-80 | + 0.25 | ||||||
