Hardness:
50-65HRC
Wear:
0.02-0.7kg/Ton Ore
Diameter Tolerance:
+1mm, -1mm
Broken Rate:
0-0.5%
Loss Roundness Rate:
0-1%
Microstructure:
M+C, P+C
Certificate:
ISO9001:2008
Balls Number:
150000 Times
Package:
Bags(One Bag=One Ton)/Drums(One Drum=800-1000kg)
Casting Metal:
Cast Iron
Casting Form Material:
Metal
Casting Method:
Special Casting
Casting Form Usage Count:
Permanent
Product Description
Jinan Huafu forging Co., Ltd, 45 km from downtown jinan, adjacent to 309 national road, information fusion and fast, the traffic is very convenient, the company covers an area of 8000 square meters, staff 100, the registered capital of three million yuan, annual production capacity of 100000 tons. The company mainly produces forging, casting, steel ball, steel forging, wrought iron products, mainly suitable for the copper, iron, gold mines, cement plants, power plants of ball mill, building decoration ball, etc. Products are mainly domestic sales and exports to the United States, in Chile, South Africa, Australia, South Korea, Japan and other dozens of countries and regions, by the customer the consistent high praise.
Main characteristic:
1. Φ 17-130mm
2. ISO9001: 2008
3. Features: High hardness;
4. Low breakage; High impact value;
5. Good wear resistance.
6. Application field: Mine; Cement plant; Power plant, construction industry.
7. Standard: YB/T17445-2010
Chemical composition and index analysis BELOW;
NAME
BRAND
CHEMICAL COMPOSITION
C
Si
Mn
Cr
Mo
Cu
Ni
P
S
Chrome casting ball
ZQCr26
2.0-3.3
≤1.2
0.3-1.5
23-30
0-3
0-1.2
0-1.5
≤0.1
≤0.06
Chrome casting ball
ZQCr20
2.0-3.3
≤1.2
0.3-1.5
18-23
0-3
0-1.2
0-1.5
≤0.1
≤0.06
Chrome casting ball
ZQCr15
2.0-3.3
≤1.2
0.3-1.5
14-18
0-3
0-1.2
0-1.5
≤0.1
≤0.06
Chrome casting ball
ZQCr12
2.0-3.3
≤1.2
0.3-1.5
10-14
0-3
0-1.2
0-1.5
≤0.1
≤0.06
Chrome casting ball
ZQCr8
2.1-3.3
≤2.2
0.3-1.5
7-10
0-1
0-0.8
-
≤0.1
≤0.06
Chrome casting ball
ZQCr5
2.1-3.3
≤1.5
0.3-1.5
4-6
0-1
0-0.8
-
≤0.1
≤0.1
Chrome casting ball
ZQCr2
2.1-3.6
≤1.5
0.3-1.5
1-3
0-1
0-0.8
-
≤0.1
≤0.1
DIAMETER
HARDNESS
BROKEN RATE
IMPACT VALUE
BALLS NO.
MICROSTRUCTURE
Chrome casting ball
ZQCr26
17-130mm
≥58
1%
6
15000
M+C
Chrome casting ball
ZQCr20
17-130mm
≥58
1%
6
15000
M+C
Chrome casting ball
ZQCr15
17-130mm
≥58
1%
5
15000
M+C
Chrome casting ball
ZQCr12
17-130mm
≥58
1%
4
15000
M+C
Chrome casting ball
ZQCr8
17-130mm
≥58
1%
3
15000
M+C
Chrome casting ball
ZQCr5
17-130mm
≥47
1%
2
12000
P+C
Chrome casting ball
ZQCr2
17-130mm
≥45
1%
1
12000
P+C
Jinan Huafu Forging Co., Ltd is located in Zhangqiu City, Shandong Province, 45 kilometers to the Jinan Downtown, next to the 309 national way, information collected fast, traffic convenient. Our company covers the 8, 000 square meters area, over 100 employees, annual output is 15, 000 metric tons. Our main products are forged, cast steel balls, steel cylpeb, decorative iron wrought products. The application for our products are mines, cement plant, building material, power station industry. Our products both sold to the domestic and foreign country. The products export to America, Chile, South Africa, Australia, Korea, Japan and other countries and regions, got highly appreciated by our customers.
Our company regulate and produce strictly according to the ISO9001 Quality Standard. The main products are:
1. Anti resistant steel ball: Dia. 20mm-dia. 150mm forged steel ball and high, medium, low chrome cast ball in dia. 17mm-dia. 120mm. Huafu steel ball is good in accurate dimension, roundness geometry shape high hardness and good mechanical properties with good characteristic of anti resistant, no deformation, no break. Huafu steel ball is uniform surface hardness, hardness distribution uniform for the advance quenching device in the producing process.
Huafu steel ball have the below characteristic: A: High hardness( surface hardness is50-65 HRC, volume hardness is 48-58 HRC with uniform hardness distribution); B: High impact toughness( above 12J/cm2); C: Low break rate( anti break is ten times compared to the normal cast and forged steel balls, factual break rate is lower than 1% when falling times is above 20, 000 from the 10 m high dropping machine) D: No deformation: Steel ball no deformation out of the round for using. Huafu steel ball is made from the perfect carbon steel and alloy steel.
2. Steel cylpeb: We absorb the advance technology, add the Cr, Mn, Si, Mg, Al, Cu and others to make the alloy cements. The products produce in the intermediate frequency furnace and fall to the high, medium, low chrome category. Its characteristic is steady quality, high hardness, anti resistant, low break rate, various kinds
3. Decorative wrought iron products: We mainly produce the forged baluster, spears, the assembles and the arctic iron door, fence, guarding windows, room furniture, various kinds for above. Our products are famous in the world by it's highly view and use value.
