| Prod Model: |
8*10mm-70*75mm |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Diameter: |
8*10mm-60*65 |
| Diameter Tolerance: |
+1mm, -1mm |
| Breakage Rate: |
0.5%-1% |
| Impact Value: |
1-7j/Cm^2 |
| Wear: |
0.02-0.80kg |
| Balls Number: |
8000-12000times |
| Microstructure: |
Low Chrome:P+C Middle&High Chrome:M+C |
| Package: |
Bag(One Bag=One Ton)or Drums(One Drum=800-1000kg) |
| Application: |
Mine, Cement Plant, Power Plant |
| Hardness: |
40-65HRC |
| Material: |
Steel |
Product Description
(1)We, Jinan Huafu Forging Co., Ltd, mainly produce grinding media for many years, with the strength of forged steel ball, cast steel ball, grinding rod and steel cylpeb. And all of our products strictly according to the ISO9001-2008 Quality Standard. The products model we can produced as follow:
Forged steel ball: Dia. 20mm-150mm
Cast steel ball: Dia. 17mm-130mm
Grinding rod: Dia. 30mm-130mm. Length: 3m-9m
Steel cylpeb: 8mm*10mm-70mm*75mm
(2)As the China sales leader in the field of grinding media our advantage:
Good quality: 45-65 HRC and no breakage, In normal use process, if the broken rate is high, we will be free for you in the new product and compensate for your losses.
Full service: From you send me inquiry until you used well, if you need any problems, could you please call me, my telephone 24 hours open for you.
(3)The production line of the cast steel cylpeb
Iron---Add Alloyed Material---Furnace Heating---Pouring to the Model---Out of the Model---Finishing---Quenching---Cooling---Tempering---Packaging
(4) Packing: Two ways
1. Bags: One bag=one ton
2. Steel drums
8*10mm-30*35mm: 1000- 900kg/drum.
40*45mm-70*75mm: 850kg/drum
(5)The chemical composition of cast steel ball as follow:
|
PRODUCT |
BRAND |
Chemical composition(%) |
|
|
|
C |
Si |
Mn |
Cr |
Mo |
Cu |
Ni |
P |
S |
|
Special high chrome casting iron cylpeb |
ZQCr26 |
2.0-3.3 |
≤1.2 |
0.3-1.5 |
>23.0-30.0 |
0-3.0 |
0-1.2 |
0-1.5 |
≤0.10 |
≤0.06 |
|
Special high chrome casting iron cylpeb |
ZQCr20 |
2.0-3.3 |
≤1.2 |
0.3-1.5 |
>18.0-23.0 |
0-3.0 |
0-1.2 |
0-1.5 |
≤0.10 |
≤0.06 |
|
Special high chrome casting iron cylpeb |
ZQCr15 |
2.0-3.3 |
≤1.2 |
0.3-1.5 |
>14.0-18.0 |
0-3.0 |
0-1.2 |
0-1.5 |
≤0.10 |
≤0.06 |
|
High chrome casting iron cylpeb |
ZQCr12 |
2.0-3.3 |
≤1.2 |
0.3-1.5 |
>10.0-14.0 |
0-3.0 |
0-1.2 |
0-1.5 |
≤0.10 |
≤0.06 |
|
High chrome casting iron cylpeb |
ZQCr8 |
2.1-3.3 |
≤2.2 |
0.3-1.5 |
7.0-10.0 |
0-1.0 |
0-0.8 |
- |
≤0.10 |
≤0.06 |
|
Middle chrome casting iron cylpeb |
ZQCr5 |
2.1-3.3 |
≤1.5 |
0.3-1.5 |
4.0-6.0 |
0-1.0 |
0-0.8 |
- |
≤0.10 |
≤0.10 |
|
Low chrome casting iron cylpeb |
ZQCr2 |
2.1-3.6 |
≤1.5 |
0.3-1.5 |
1.0-3.0 |
0-1.0 |
0-0.8 |
- |
≤0.10 |
≤0.10 |
Jinan Huafu Forging Co., Ltd is located in Zhangqiu City, Shandong Province, 45 kilometers to the Jinan Downtown, next to the 309 national way, information collected fast, traffic convenient. Our company covers the 8, 000 square meters area, over 100 employees, annual output is 15, 000 metric tons. Our main products are forged, cast steel balls, steel cylpeb, decorative iron wrought products. The application for our products are mines, cement plant, building material, power station industry. Our products both sold to the domestic and foreign country. The products export to America, Chile, South Africa, Australia, Korea, Japan and other countries and regions, got highly appreciated by our customers.
Our company regulate and produce strictly according to the ISO9001 Quality Standard. The main products are:
1. Anti resistant steel ball: Dia. 20mm-dia. 150mm forged steel ball and high, medium, low chrome cast ball in dia. 17mm-dia. 120mm. Huafu steel ball is good in accurate dimension, roundness geometry shape high hardness and good mechanical properties with good characteristic of anti resistant, no deformation, no break. Huafu steel ball is uniform surface hardness, hardness distribution uniform for the advance quenching device in the producing process.
Huafu steel ball have the below characteristic: A: High hardness( surface hardness is50-65 HRC, volume hardness is 48-58 HRC with uniform hardness distribution); B: High impact toughness( above 12J/cm2); C: Low break rate( anti break is ten times compared to the normal cast and forged steel balls, factual break rate is lower than 1% when falling times is above 20, 000 from the 10 m high dropping machine) D: No deformation: Steel ball no deformation out of the round for using. Huafu steel ball is made from the perfect carbon steel and alloy steel.
2. Steel cylpeb: We absorb the advance technology, add the Cr, Mn, Si, Mg, Al, Cu and others to make the alloy cements. The products produce in the intermediate frequency furnace and fall to the high, medium, low chrome category. Its characteristic is steady quality, high hardness, anti resistant, low break rate, various kinds
3. Decorative wrought iron products: We mainly produce the forged baluster, spears, the assembles and the arctic iron door, fence, guarding windows, room furniture, various kinds for above. Our products are famous in the world by it's highly view and use value.
