| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Quality Control: |
Strict Inspection as Per Standard |
| Material: |
Iron |
| Connection: |
Female |
Product Description
Details of SYI Steel Forged Mechanical Fitting:
Standard:
ASME/ANSI B16.11, B 1.20.1, MSS SP-79, 83, and JIS B 2316, GB/T 14626
Materials:
ASTM A 105, ASTM A 182 F304, F304L, F316, F316Land so on
Nominal diameter: 1/8 to 4 inches (DN6 to DN100)
Pressure rating:
1)Threaded: 2, 000, 3, 000, and 6, 000lbs;
2)Socket weld: 3, 000, 6, 000, and 9, 000lbs
Ends: Socket weld and threaded NPT
Types:
Union, 90 degrees elbow, 45 degrees elbow, tee, cross, cap, coupling, nipple, outlet, lateral, reducer insert, bushing, plug, boss and threaded short pipe
Packing: Standard export package or as per your requirements
Application: Petroleum, chemical engineering, electricity benefit, building and water conservancy
PRODUCTION EQUIPMENT | TYPE | QTY | SIZE | TOLERANCE |
CNC Lathe | turning | 120 sets | MAX OD 120mm | Min +/-0.01mm |
Punch | hot forging | 3 sets | 60-80 tons | +/-0.05mm |
| | cold stamping | 29 sets | 15-100 tons | +/-0.05mm |
Hydraulice press machine | hot&cold press | 2 sets | 315-500 tons | +/-0.02mm |
Rolling machine | threading and diamond rolling | 2sets | Max OD 25mm | +/-0.05mm |
More information is available upon receipt of your enquiry.
You will get our quick reply!
