| Prod Model: |
CPMP1580 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
CNC Punching Machine for Plate Model CPMP1580
Our company bases everything on Technology and Service; Self-reliance innovation, harmonious development. Colleagues are well welcomed for exchanges and cooperation. Let's prosper the steel structure market and seek common development and benefits together.
| Object | Item | CPMP1580 |
| Work piece | Thickness | 6~25mm |
| Length × Width | 1500× 800mm |
| Punching | Max. punching capability (Dia. ) | Φ 31.5mm ( when the thickness less than 16mm) |
| Min. distance from edge to the hole | 25mm(when diameter ≤ 25.5mm) |
| Punching power | 1000KN |
| Marking | Marking number | 14 (two rows) |
| Size of marking | 14× 10mm |
| Marking power | 800KN |
| Clamping | Thickness of clamping | 5~40mm |
| Number of clamping cylinder | 2 |
| Power | 10KN |
| Control | By the push button |
| Module position | Number | 3 |
| Precision | According to the standard of GB2694-81 |
| Electric system | Control mode | CANOPEN bus control |
| nominal torqueof X and Y axes servo driving | 11.1NM |
| Rated speed of X and Y axes servo driving | 2500rpm |
| Hydraulic system | High voltage | 25Mpa |
| Low voltage | 6Mpa |
| Motor power | 22KW |
| Machine dimension | Length × width × height | 3020× 3035× 1875mm |
| Total weight |
| 8000Kg |
Our company concentrates on the field of steel structure, petrol chemical and pressure vessel. Based on absorbing technical advantages of peer CNC equipments from domestic and international colleagues, we keep improving our products and provide cost-effective, user-friendly and reliable metal processing machinery. In current stage, the major equipments we produce and sell include CDMP series CNC plate drilling machines used for the processing of connection boards, BDM series CNC 3-D drilling machines used for the processing of section steel, SAW series CNC band sawing machines, SUK series section steel beveling machines and DM series CNC drilling machines for the processing of boilers, petrol, chemical plant pressure vessel and heat exchange, etc.
Our company centers on R&D. We entrust the processing of some parts to processional manufacturing companies and accomplish the assembly and adjustment of the complete machines by ourselves. First class products from the world famous enterprises are adopted for all key parts in our products, such as of electricity, hydraulic pressure, and mechanical drive and so on. In addition, there is strict QA management through the procedure in production and assembly, which can help to enhance the reliability and stability for the operation of our equipments.
A series of CNC drilling machines of VISTA have been exported to Korea, Russia, Ukraine, Iran and India for many times. Our company concentrates on enhancing organization management level of enterprise, makes efforts to perfect quality management system of production. And GB/T 19001-2000-ISO9001 has been certified in August, 2005.
Our company bases everything on Technology and Service; Self-reliance innovation, harmonious development. Colleagues are well welcomed for exchanges and cooperation. Let's prosper the steel structure market and seek common development and benefits together.
