| Prod Model: |
TF39.6-200-800 |
Product Description
MATERIAL:
(1)Coil Width: 1000 mm
(2)Suitable Coil Thickness: 0.3mm - 0.6mm
(3)Suitable Raw Materials:
Pre-painted Coil; Yield bearing stress: 235MPa
MACHINE COMPONENTS:
(1) Manual Un-coiler 1 set
(2) Roll-Forming M/C 1 set
(3) Hydraulic Pressing Die/Cutting M/C 1 set
(4) PLC Control System 1 set
TECHNICAL SPECIFICATION
(1)Manual Un-coiler:
Un-powered; Max. Capacity: 5 ton
*Hydraulic Un-Coiler(option):
Hydraulic system to expand coil inner hole;
Frequency Inverter to regulate turning speed;
Automatic stop device; Load capacity = Max. 5Tons;
(2) Roll-Forming M/C:
Gear/Sprocket driving; 13-step to form
Forming speed: Approx. 3-6m/min;
(3) Hydraulic Pressing Die & Cutting M/C:
Stop to cut, Pressing die and Post cut
Material of Pressing tool: Cr40, Heat treatment; Pressing Depth: 15mm
Material of cutting tool: Cr12
(4) PLC Control System:
Control the quantity, cutting length automatically
Cut-to-length tolerance +/-3.0 mm
Option:
Hydraulic un-coiler
Hydraulic system to expand coil inner hole;
Frequency Inverter to regulate turning speed,
Automatic stop device; Load capacity = Max. 5Tons;
