Custom Alunimum Housing Die Casting Mould Part

Name: Custom Alunimum Housing Die Casting Mould Part
Brand: china-castingforging.com
SKU: 761567915
Availability: InStock
Rating: 4.6 (134 reviews)

Price:	US $ 500-10000/Piece
Trade Terms:	FOB,DDP,CIP
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Kunshan Grand Precision Mould Co., Ltd.

Showroom Product Company Profile

Prod Model:	YB-W102
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Brand:	Grand
Product Name:	Die Casting Muld/ Part
Size:	400mm300mm400mm
Weight:	50kgs-150kgs
No. Of Cavity:	Single / Muti
Surface Finish:	Polishing, Sand Blasting, etc.
Processing:	Milling, Lathe,CNC, Hot Treatment, Grinding, Wirec
Precision:	0.005mm-0.002mm
Mould Life:	500k~1200k Shots
Lead Time:	5-15days
Surface Preparation:	Polishing
Die Casting Machine Type:	Cold\ Hot Chamber Die Casting Machine
Application:	Machinery/ Auto Parts
Material:	Aluminum/Aluminum Alloy
Pressure Chamber Structure:	Vertical/ Horizontal
Casting Surface Quality Level:	2/3
Certification:	Ts16949

Product Description

Specifications

Product Specification	Product Name	die casting moulds / die casting parts
	Mould Material	Steel 45#, 50#, 60#, P20. 718, 2083, etc.
	Standard	HASCO,DME,LKM,etc.
	Color	single-colored, double-colored and multi-colored
	Size	as per customer's requirement.
	Weight	50kgs-150kgs
	No. of Cavity	Single / Muti
	Runner	Hot/ Cold
	Surface Finish	polishing, sand blasting, etc.
	Processing	milling, lathe,CNC, hot treatment, grinding, wirecutting, discharge, etc.
	Precision	0.005mm-0.002mm
	Mould Life	500K~1200K Shots
	Certificated	ISO9001:2008; TS16949
	Lead Time	5-15days
	Annual Output	450 sets of mold
Order Specification	MOQ	1 set of mold
	Trade Terms	FOB,EXW
	FOB Price	US $ 500 - 10,000 / set
	delivery time	about 4-6 weeks, according to your order
	Payment term	T/T, L/C, Western Union
	Payment condition	30% deposit in advance, balance 70% before shipment
	Shipping	By Sea, By Air and By Express Delivery
	Package	fresco bag, wooden case and pallet, be of rust-proof protection and suitable for shipment
	Supply Ability	100 Set/Sets per Month
	Port of loading	Shanghai/ Suzhou port
	Offer OEM/OED	Yes

Customer Services

Full service system:
1.Technology service.
2.Customize service
3.Design service
4.Supporting service
5.Secrecy service
6.Aftermarket service

Business scope:
1.Development &. Technical Service of Precision Moulds, including plastic injection moulds, metal moulds and die casting moulds.
2.Development &. Technical Service of Precision Mould parts, including plastic mould parts, metal mould parts, die casting mould parts and standard parts.
3.Development &. Technical Service of Precision Mould Plastic product parts, including auto plastic parts, medical device parts, household appliance parts, electronic parts, electronic tool parts, etc.
Main partner:

MAGNA

MAHLE

swoboda

Hengst

Amphenol

Whirlpool

Quality Control &. Certificates

Strict quality control system: ERP SYSTEM

3D / 2D files→→→Test to raw material→→→Independent inspection→→→Final test→→→Shipment
Design IPQC FQC IQC
Note:
EPR system is applied in management to guide us a more scientific and efficient jobs, from purchasing material to mold assembly, we are trying our best to make every step perfect.
All departments manufactured exactly according to the technology parameter and make independent inspection, according to , and then, we will have all tools inspected by our quality control department before we transfer to customers.

Quality inspection apparatus:

Tool Microscope	0-600 Altimeter	Hardness Tester	3 Dimension Coordinates	Wolfram Gauge Block	SKH-9 Gauge Brock	Projector	Needle Gauge
3+1	3	1	1	5	5	2	5

Quality certificates: TS16949; ISO9001:2008

Quality policy: No quality, no Grand tomorrow.

About Grand

Grand Precision Mould Co., Ltd is a modern company which provides a complete service, including the development and technical services of precision mould, mould parts and plastic product parts. It is located in Kunshan city, Jiangsu province with geographical position superiorly and transportation convenience.
Grand upholds the principle of "Quality First, Credit First", taking the mission of creating an excellent team in the precision mold industry.
Registered capital: 5 million RMB
Fixed asset investment: 40 million RMB
Total staff: 140
Industry experience: 10 years
Advanced equipments:

Speed CNC(F5)	Speed CNC(F3)	Feeding Wire-Cut (AQ360Ls: minimum ø 0.1mm wire)
Makino high	Makino high	Sodick Slow

Spark Machine (EDGE3,EDGE2)	Engel Injection Machine	Feeding Wire-Cut (AG600L: minimum ø 0.1mm wire)
Makino	HAITAIN	Sodick Slow

Order Flow

1.Sample/Drawing	We need your detail requires clearly.
↓
2.Negotiation	Material, cavity, price, delivery time, payment term ,etc.
↓
3.Place order	According your own design or choose our engineers' design.
↓
4.Mould design	We will communicate&.exchange the opinion with you during making drawing.
↓
5.Tooling mould	After customer approving the mould design, mould making start.
↓
6.Mould process	Provide photos for customer showing tooling process.
↓
7.Sample confirm	Send you sample for confirm it, if not satisfied, we will modify the mould.
↓
8.Delivery mould	Delivery mould after customer sample approval and arrange shipment.

Question &. Answer:

1.  Q: What are your primary product lines?
A: According to product form, we mainly manufacture or process moulds, mould parts and mould products.
According to industry classification, our products spread over auto, mechanical, electronic, household appliances and machinery fields.

2.  Q: Why choice Grand?
A: 1).Strict quality control to meet customer's requirements.
2).Complete cost control system to be cost-effective.
3). Good Pre-sale, In-sale and After-sale Services.
4). Rich experience in mold design and manufacture.
5). Punctual delivery.
3. Q: How to get an efficent quotation?
A: To offer an efficient quotation, we need:
1). 3D model and 2D drawing of parts;
2). Quantity, Material, and other special requirements.
But it's okay if you could only sketch the product, our engineers will do everything to help you.
4.  Q: How long does it cost to get an quotation?
A: Usually, we will send the quotation in 24hours after receiving all the necessary details.
