| Prod Model: |
T type |
| Markets: |
Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Inspection: |
100% Water Pressure Test |
| Internal Protection: |
Cement |
| Outernal Protection: |
Zinc+Bitumen |
| Usage: |
Water Supply |
| Type: |
Ductile Iron Pipes |
| Section Shape: |
Round |
| Certification: |
EN545 |
| Customized: |
Non-Customized |
Product Description
1), Product
The ductile iron pipe manufactured by vortex are mainly used for transferring the drinkable water, waste water and for irrigation.
The diameter is from DN80-DN2000, K8/K9/K10/K12, Tyton socket and spigot, the standard length is 6m.
2), Standard
*conform to ISO2531/EN545/EN598/4179/8179
3), Material
* Ductile Iron GGG500-7&400-12 or ASTM-A-536grade 80-55-06
4) coating
* Metallic zinc spray with Bituminous Coating (Outside) Cement mortar lining (Inside). Epoxy coating available upon request.
5), Joint method available
*Push-on
6), Process
* centrifugal casting
7), Inscription Style
* As per customers' requests
* Standard Inscription
8), Packing
* standard export bundle
* in bulk
* As per customers' requirements
9), Inspection
* Foundry in-house
* Third Party inspection available upon request
|
Test pressure (Bar) >=15second |
| Nominal Diameter | Ductile Iron Pipe(k9) | Ductile Iron Pipe(C class) | Ductile Iron Fitting |
| 80-300 | 50 | C40 | 25 |
| 350-600 | 40 | C30 | 16 |
| 700-1000 | 32 | C25 | 10 |
| 1100-1200 | 25 | - | 10 |
| 1400-1600 | 25 | - | 10 |
| 1800-2000 | 25 | - | 10 |
| 2100-2600 | 18 | - | 10 |
VORTEX Qingdao Co., Ltd., as a big and professional manufactural factory based in Qingdao city Of China, we have three foundries, and our main products are ductile casting iron products water-supplying pipeline field, typical products as below.
Our typical products are as below:
Ductile iron pipe and fitting (Size from DN80 to DN2000),
**** Ductile iron pipe K9/K8/K7/ C class, Socket bend, flanged bend, socket and flanged tee, flanged socket, flange taper, socket taper, blank flange, welding flange, bellmouth.
**** Welding flanged pipe, we have Automatic welding equipment to produce welding flanged pipes and one of best stable welding quality in China.
**** Pipe joint, including Flanged adapters, Couplings, Dismantling joints, Clamp, and stainless steel repair Clamp, all like Viking Johnson design joint with EPDM gasket rubber rings.
**** PVC pipe fittings from DN50----DN630.
**** Loose flange fittings from DN80----DN600.
****Gate valve, Check valve, Butterfly valve, Air valve, Angel valve, Fire hydrant, Extension spindle,
All of them are according to ISO2531/EN545/EN598/AWWA C110/C153. (PN10/PN16/PN25/PN40)
Furthermore, we can supply pipe fittings with Rilsan Nylon power coating(black color) and epoxy resin AKZOL powder coating, so far we are the few supplier of Rilsan Nylon coated fittings.
