Flange Protectors

Flange Protectors
Price: US $ 0.02-0.04/Piece
Trade Terms: FOB,EXW
Min Order: 1000/Piece
Pay Type: T/T
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe

Product Description

  FREE SAMPLES, SUFFICIENT STOCK AND AVAILABLE MICRO-PACK

MOCAP LDPE Sheet Metal Hole Plugs are flush head designed for standard hole sizes. Snap-in sheet metal hole plug provides an attractive finish and a secure fit. MOCAPpolyethylene plastic flush head sheet metal hole plugs are used to cap plug holes on appliances, automobiles, tanks or anywhere a finished look is needed. SMFS Series sheet metal plugs available in sizes to fit 3/8" to 4" diameter holes.


Provides a Finished Look
Snap In Design for a Secure Fit
Designed for Sheet Metal and Thin Gauge Materials

Also Available:
Flush Head sheet metal hole plugs to fit 8mm to 22mm holes.
Recessed Head sheet metal hole plugs to fit 1/2" to 2-1/2" holes.

MOCAP stocks Sheet Metal Hole Plugs Flush Standard in many sizes for immediate shipment.



Part #
To Fit Hole SizeMetal Thickness(A)(B)(C)BoxMiniMicro
Small O.D.Flange ODLengthQTYPackPack
inmminmminmm


SMF3/8BK1.37"- .38" (9.40 - 9.65mm).02"- .06" (.51 - 1.52mm)0.4110.40.7519.10.194.850001000100
SMF7/16BK1.43"- .45" (10.92 - 11.43mm).03"- .06" (.76 - 1.52mm)0.4711.90.6917.50.225.650001000100
SMF1/2BK1.49"- .52" (12.45 - 13.21mm).03"- .08" (.76 - 2.03mm)0.5413.70.8621.80.256.450001000100
SMF9/16BK1.55"- .58" (13.97 - 14.73mm).03"- .08" (.76 - 2.03mm)0.615.20.8722.10.256.450001000100
SMF5/8BK1.61"- .64" (15.49 - 16.26mm).03"- .08" (.76 - 2.03mm)0.67170.9323.60.266.650001000100
SMF3/4BK1.74"- .77" (18.80 - 19.56mm).03"- .11" (.76 - 2.79mm)0.7920.11.0626.90.297.450001000100
SMF7/8BK1.86"- .89" (21.84 - 22.61mm).03"- .08" (.76 - 2.03mm)0.9123.11.1629.50.256.450001000100
SMF15/16BK1.92"- .96" (23.37 - 24.38mm).03"- .08" (.76 - 2.03mm)0.9824.91.3133.30.256.450001000100
SMF1BK1.96"- 1.02" (24.38 - 25.91mm).03"- .08" (.76 - 2.03mm)1.0426.41.3734.80.256.450001000100
SMF1-3/16BK11.17"- 1.20" (29.72 - 30.48mm).03"- .08" (.76 - 2.03mm)1.22311.5639.60.256.450001000100
SMF1-1/4BK11.23"- 1.27" (31.24 - 32.26mm).03"- .08" (.76 - 2.03mm)1.2932.81.6241.10.256.450001000100
SMF1-5/16BK11.30"- 1.33" (33.02 - 33.78mm).03"- .08" (.76 - 2.03mm)1.3634.51.6842.70.256.4450090090
SMF1-1/2BK11.49"- 1.52" (37.85 - 38.61mm).03"- .08" (.76 - 2.03mm)1.5439.11.8847.80.256.4350070070
SMF1-3/4BK11.73"- 1.76" (43.94 - 44.70mm).03"- .08" (.76 - 2.03mm)1.7945.52.1354.10.256.4100020020
SMF2BK11.98"- 2.01" (50.29 - 51.05mm).03"- .08" (.76 - 2.03mm)2.0451.82.3659.90.297.4100020020
SMF2-1/8BK12.10"- 2.14" (53.34 - 54.36mm).03"- .08" (.76 - 2.03mm)2.1755.12.4963.20.256.4100020020
SMF3BK12.97"- 3.02" (75.44 - 76.71mm).03"- .08" (.76 - 2.03mm)3.0677.73.3685.30.256.475015015
SMF3-1/8BK13.10"- 3.15" (78.74 - 80.01mm).03"- .08" (.76 - 2.03mm)3.1880.83.5289.40.256.475015015
SMF3-3/8BK13.35"- 3.40" (85.09 - 86.36mm).03"- .08" (.76 - 2.03mm)3.4387.13.7595.30.287.150010010
SMF3-1/2BK13.47"- 3.52" (88.14 - 89.41mm).03"- .11" (.76 - 2.79mm)3.5690.43.86980.287.150010010
SMF4BK13.97"- 4.02" (100.84 - 102.11mm).05"- .10" (1.27 - 2.54mm)4.07103.44.371110.287.150010010

MOCAP offers more Caps, Plugs, Grips, Tapes, Tubing and Netting
to satisfy your Product Protection, Masking and Finishing needs.

For over 25 years MOCAP has been the Industry Leader in manufacturing quality DIP Molded Vinyl, Injection Molded Plastic and Injection Molded Rubber products for virtually every market.

MOCAP has again expanded its product lines by adding additional families of Polyethylene Caps and Plugs including Tapered Caps and Plugs, Center Pull Taper Plugs, Flanged Caps, Straight Caps, Sheet Metal Plugs, Tubing End Caps and Plugs. Recently added Vinyl Plastic DIP Molded items include square caps, hex caps, corner covers, hanger caps and collar guard bend restrictors.
