| Prod Model: |
FIT |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Brand Name: |
Focusun |
| Capacity: |
1-100tons |
| Application: |
Industrial |
| Control: |
Electric |
| Material: |
Stainless Steel |
| Power: |
200W-400W |
| Structure: |
Integral Type |
| Condensing Mode: |
Water-Cooled |
| Ice Shape: |
Tube |
| Automatic Cleaning Device: |
With Automatic Cleaning Device |
| Filtering Device: |
With Filtering Device |
Product Description
Insert Special Characters
Focusun Triumph Series Tube ice machine Technical Data Model Daily Capacity Compressor Wattage Refrigerant Power Supply FIT50 5000kg BItzer 15kw R22/R404A 220V/60Hz, 380V/50Hz, FIT100 10, 000kg BItzer 32.75kw R22/R404A 220V/60Hz, 380V/50Hz, FIT100 15, 000kg BItzer 37.5kw R22/R404A 220V/60Hz, 380V/50Hz, FIT200 20, 000kg Bitzer/Grasso 56.6/45.3kw R22/R717 220V/60Hz, 380V/50Hz, FIT250 25, 000kg Bitzer/Grasso 67.8/53.4kw R22/R717 220V/60Hz, 380V/50Hz, FIT300 30, oookg Bitzer/Grasso 85/62.8kw R22/R717 220V/60Hz, 380V/50Hz, FIT400 40, 000kg Bitzer/Grasso 113.2/81.7kw R22/R717 220V/60Hz, 380V/50Hz, Salient Features of Big Capacity Tube Ice Machine:
- Capacities offered: 5, 000Kgs/24H to 40, 000Kgs/24H.
- Simple design/engineering.
- No requirements of skilled workers.
- High durability, minimal maintenance.
- High energy efficiency.
- Complete spare parts provided. Machine Components of this Big Capacity Tube Ice Machine:
- SS304 stainless steel tube ice machine
- Water Distributors: Made up of elastic material which creates a continuous and uninterrupted peripheral seal between the tube ends and water distributor.
- Refrigerant: R22/R404A/Ammonia.
- Freezer: High quality stainless steel for all water and ice contacting surfaces which are corrosion resistant and easy to clean.
- Cutter: Stainless steel cutters driven by gear motors are uniquely designed to produce both cylindrical and crushed ice simply by reversing the motor of cutter and using a switch on the control panel that controls this function.
- Cutter Motors: Built with heavy duty design to give years of reliable ice-cutting service.
- Pumping Tank (Water Pumps): Centrifugal casting iron pump is large enough to circulate the quantity of water to be frozen for many times and produce crystal clear ice.
- Control Panel: Access to the automatically electrical system which performs sequences of freezing and thawing precisely and dependably year after years. 2004
- Maximum 4, 000 characters.
Focusun Refrigeration is the most professional manufacturer in China, specialized in designing and manufacturing of high quality ice making machines, such as: Flake ice machine, cube ice machine, tube ice machine, and block ice machine. We have earned the position of dependable supplier among a vast global clientele due to consistency in quality of our product range and services offered to the clients.
As a well established manufacturer and exporter, we lay special attention to our manufacturing process and delivery of products: Flake ice machine, cube ice machine, tube ice machine, and block ice machine. We take utmost care of quality at every stage of the manufacturing process. Our staff of highly qualified engineers combines the benefits of irreplaceable practical experience with the sophisticated accuracy of our own interactive graphics computer system enable us to provide high quality product, prompt deliveries, dependable service, and outstanding customer satisfaction.
Focusun is known across the country for our premium quality on the products we offer. We have a hi-tech production unit that uses the latest technology and the most modernized machinery. We have a strong and proficient workforce, comprising of technically skilled professionals and efficient workers. Our research and development wing is our asset that develops and incorporates innovative ideas and products.
Our products: Flake ice machine, cube ice machine, tube ice machine, and block ice machine are globally known for their dimensional accuracy, high efficiency & durability and they are used in various fields such as aquatic food processing, supermarkets, healthcare centers, man-made skiing resort, mines, large-scale concrete construction, etc. The product model ranges from small-sized ice machines with a daily output of 230kgs to large-sized sets of ice making system up to 60tons in 24hours and 85% of our ice making machine's components are imported and all undergo rigorous monitoring and quality control system to ensure superb quality of our flake ice machine, cube ice machine, tube ice machine, and block ice machine.
We pride ourselves on quality, service and pricing, and believe that all three areas are equally important to ensure the long-term success of your overseas purchasing program. Our sustained relationship with customers serves as testimonial for our high quality products. The fusion of superior quality and reasonable prices make our products capable of influencing anyone in the whole world. Our reputation in the market is synonymous with high quality, updated technology and dedicated approach.
