Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Deformation Temperature: |
Hot Forging |
Molding Style: |
Forging |
Product Description
1. Material: Forged square steel bar
2. Diameter: 100mm-1000mm
3. Length: 2000mm-12000mm Straightness: 3mm/M max;
Square bar. 100-1000mm, blocks sizes up to 800*1000mm
4. Process: EAF + LF + VD + Forged + Heat Treatment (optional)
5. Delivery condition: Hot forged +Rough machined (black surface after Q/T) Turned (optional)
6. Delivery Time: 30-45 days
7. MOQ: 20 tons
8. Heat treatment: Normalized / Annealed / Quenched / tempered
9. Forged ratio: No less than 3: 1
10. Technical Data: AComposition, Physical Properties and Mechanical Testing according to the customer's requirement of Chemical
11. Test: Ultrasonic test according to SEP 1921-84 G3 C/c
12. Certificate of Quality issued in English, in addition the normal terms, production process, the mechanical property (yield strength, tensile strength, elongation and hardness), forged ratio, UT test result, Grain size, heat treatment methods and the sample of is shown on the Certificate of Quality
13. Marking: Grade, heat NO. Length will be stamped one each bar with required color
14. Payment: 30% advance by T\T; Balance pay before the shipment against shipping documents or irrevocable LC at sight
15. Application: Statically and dynamically stressed components for vehicles, engines and machines. For parts of larger cross-sections, crankshafts, gears.
