| Prod Model: |
CH |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Material: |
Stainless Steel |
| Surface Treatment: |
Powder Coating, Painting, Spraying, Galvanize |
| Casting Metal: |
Cast Steel |
| Casting Form Material: |
Metal |
| Casting Method: |
Special Casting |
| Casting Form Usage Count: |
Semi-permanent |
Product Description
Precision Casting, Investment Casting & Lost Wax Casting. Carbon steel/Alloy steel/Stainless steel. Polishing/Shot blast surface.
Features to Precision Casting, Investment Casting & Lost Wax Casting:
1. Material & standard:
Stainless Steel SUS304 SUS316 Alloy Steel
2. Technology: Lost wax process or Silicon sol shell-making.
3. Melting equipments: Medium frequency induction electric furnaces.
4. Inspection facilities: Spectrum instrument, ultrasonic flaw detector X-ray detecter, and mechanical properties facilities.
5. Heat treatment: Ageing, normalizing, quenching & tempering(if necessary).
6. Surface treatment: Shot blast surface or polishing surface.
7. Machining: CNC, NC, common machines process(if necessary).
8. Part Unit weight range: From 0.1kg up to 60.0kgs
9. Representative product: Casing, housing, cover, gear, connection part, bolster, frame, link push, bucket teeth, hammer, ball, pipe fitting.
|
1.Technology |
Silica sol binder, Lost wax, Investment casting process |
|
2.Variety of materials |
Carbon steel, Alloy steel, Stainless steel, Ductile iron etc. |
|
3. Standards |
ASTM, JIS, BS, DIN, EN, ISO |
|
4. Capacities |
3,000,000 pieces/Month or 150Tons/Month |
|
5. Field of applications |
Textile & sewing machine parts, Packaging & printing machine parts, Machinery parts, Auto parts(Valve), Marine hardware parts, Lock parts, Electric tools parts, Hardware tools & other fields |
|
6. Products advantages |
Casting dimensional accuracy can reach CT3-CT4 grade
Casting no internal shrinkage, external shrinkage defects
Casting black spots after polishing can be controlled with 3%
Casting internal tissue density is good to ensure the heating treatment
and machining can be done well
Casting surface roughness good, significantly reduce the working hours of casting burning and polishing |
|
7.Material |
SS:303,304,304L,316,316L,CF8,CF3,CF8M,CF3M,1.4308,1.4408,1.4404,SCS13,SCS14,CD4,5AA |
|
CS:C20, C40, C45, WCB, WCC , 4340 etc |
|
AS: 15Cr3, 15CrNi6, 16MnCr5, 42CrMo4, 35CrMo, 40Cr etc |
Century HH is your professional friend which specialized in various kinds of casting and machining parts in China especially in Shandong province. During last 15 years, we rooted in the boom of Casting and Machining industry of Shandong province. After continuous accumulation and innovation, Cetury HH now can supply casting by different methods for example Lost Foam Casting Precision Shell Casting Lost Wax Casting Resin Sand Casting Normal Sand casting and Die casting. The main material we can cast are Iron (Ductile and Grey) Iron Alloy Steel Steel Alloy and Aluminum.
Our mission is to give you a whole solution for your product. It contains drawing design mold design manufacturing process selection and quality test. We adhere to the belief for customer High Quality High Efficiency and Low Cost for customer. Thanks to the customers support and trust, we can take a place in this field.
