| Prod Model: |
As your requirement |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Condition: |
New |
| Brand Name: |
Yuhong |
| Capacity(T/H): |
0.65-100 |
| Model Number: |
Various |
| Certificate: |
ISO 9001:2008 |
| Color&Material: |
as You Request |
| Output Size: |
0.075-0.4mm |
| Feed Particle Size: |
≤20-25(Mm) |
| Power: |
18.5-800kw |
| Weight Of Ball: |
1.5-110 (T) |
| Type: |
Ore Grinder |
Product Description
Application:
Ball mill is widely used in cement, silicate products, new building materials, refractory materials, fertilizer, ferrous and non-ferrous metal mineral as well as glass ceramics and other production industries of all kinds of ores and other grind-able materials which could be dry or wet grinding.
Performance Characteristics:
The equipment consists of feeding, discharging part, turning part, a transmission part ( reducer, small transmission gear, motors, electrical control) and other major parts. Hollow shaft with steel castings, the liner is detachable, rotary gear hobbling with casting. Its cylinder liner wear studded body, has good abrasion resistance. The machine is running stable, reliable work.
Working Principle:
Ball mill is a horizontal cylinder with rotary device, outer gear, double warehouses, grating type ball mill. Material from the feed device evenly into the mill screw shaft first warehouse, the warehouse has stepped lining board or corrugated liner, which is built with different specifications of steel balls, the rotation of the cylinder to generate centrifugal force will bring the steel ball to a certain height after the fall, the material produces severe impact and abrasive. Materials in the first position to coarse grinding, the board by the single compartment into the second warehouse, the warehouse lined with flat lining, steel ball inside, the material to further grinding. Powder through the discharge grate and finish grinding operation
