| Prod Model: |
EX-F-05 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Graphite Mold |
| Carbon Content: |
High-Carbon |
| Grade: |
Industrial Grade |
| Forming Way: |
Molded Graphite |
| Crystal Morphology: |
Compact Crystalline Graphite |
| Composition: |
C |
Product Description
The high strength &density graphite has the properties of fine gains. Uniform structure, and isotropy. It is typically used as the heater of vacuum furnace and high-frequency furnace, the crucible and mould for smelting metals. The internal lining of reduction furnace, mechanical sealing ring in the erosive medium adnd in dusty ambniance.
High strength graphite for EDM, Continuous casting
1). EX-F-051
Compressive strength: 78 MPa
Resistivity: 10 micro. Ohm. M
Bending strength: 37 MPa
Density: 1.80 g/cm3
Hardness Shore: 48
Ash: 0.1%
Dia100X250
Dia135X250
Dia150X250
Dia200X250
Dia300X500
650 X 300 X 200
250 X 130 X 100
280 X 140 X 100
300 X 100 X 80
320 X 120 X 120
400 X 120 X 120
2). EX-F-052
Compressive strength: 86 MPa
Density: 1.90 g/cm3
Resistivity: 10 micro. Ohm. M
Bending strength: 42MPa
Compressive strength: 86 MPa
Ash: 0.1%
Hardness Shore: 50
250 X 130 X 100
280 X 140 X 100
300 X 100 X 80
400 X 120 X 120
3). EX-F-053
Compressive strength55MPa
Density1.82 g/cm3 (impregnated 3 times, baked 4 times)
Dia35X75mm
Dia50X65mm
Dia90X100mm
Dia160X165mm
Dia175X260mm
375X165X110mm
420X140X100mm
70X45X4mm
4). EX-F-054
Height 100mm: Dia60, 70, 90, 110
Height 240mm: Dia135, 155, 167, 190, 210, 225, 245, 250, 270, 300, 320
Height 140mm Dia80
Block 250 X 480 X 100mm; 130X510X90-100mm
100 X 260 X 260; 100 X 240 X 440
Chinese Graphite & Carbon Limited is a professional manufacturer for mainly producing special graphite, graphite electrode (NP, IP, HP, UHP and ORC), graphite anode, and other graphite products for 20 years. Our parent company (our factory), is located at the northeast of Inner Mongolia China. The annual capacity of graphite blocks is 10000tons. It will be 15000 tons in 2014. Other graphite products are 10000 tons yearly. Due to the high quality, the products are sold to 30 provinces, cities and autonomous regions and exported to more than 20 countries and regions such as Southeast Asia, Japan and South Korea, Europe, the Americas and Africa, and so on.
As a professional, graphite products business of the company, we also operate as pyrolytic graphite, graphene, carbon fiber, not permeability graphite, carbon brush and other various carbon and graphite products. We warmly welcome your visit of our Inner Mongolia plant for our friendly long time co-operation!
