Heavy Cast Iron Plate with Slots

Prod Model:	DEYI0220
Markets:	South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Name:	Heavy Cast Iron Plate with Slots
Specification:	200mm*100mm to 3000mm*8000mm
Material:	Ht200-Ht300, Qt400-700
Accuracy:	0.03-0.3mm
Brinell Hardness:	170-240 Hbw
QA1:	Physical and Chemical Inspection Report
QA2:	Metallographic Examination, Dim Inspection Report
QA3:	Customer Requirements Reports.
Packaging:	Wooden Cases, Steel Cases, Cartons
Brand:	Deyi
Type:	Clay Dry Sand

Product Description

Heavy Cast Iron Plate with Slots


Botou Deyi Heavy Industry Manufacturing Co.,Ltd is specialized cast iron surface plate manufacturer and a professional company which is engaged in casting , machining, machine tool supporting.
Main prodcuts are Cast Iron Surface Plates/Platforms And Measuring Tools,
Machine Tool Castings And Accessories, Magnesium Alloy Measuring Tools,
Granite Surface Plates/Platforms And Measuring Tools, Precision Alloy Castings and so on, and the material are graphite cast iron, ductile iron, heat-resistant corrosion-resistant cast iron, carbon steel, alloy steel, gray cast iron, chromium and molybdenum copper alloy cast iron and so on.

We can offer high quality product with competitive price with relatively short lead time.

CAST IRON SURFACE PLATE SPECS DESCRIPTION
CODE	SPECS(mm)	PRECISION
		" 0" CLASS (μ m)	" 1" CLASS (μ m)	" 2" CLASS (μ m)	" 3" CLASS (μ m)	FINISH PLANE      (μ m)
01	200× 100	5	10	20
02	200× 200	5	10	20
03	250× 250	5.5	11	22
04	300× 200	6	12	24
05	300× 300	6	12	24
06	400× 300	6	12	24
07	400× 400	6	12	24
08	500× 300	6	12	24
09	500× 350	6	12	24
10	500× 450	6	12	24
11	500× 500	7	14	28
12	600× 450	7	14	28
13	600× 500	7	14	28
14	700× 500	8	16	32	80
15	800× 500	8	16	32	80
16	800× 600	8	16	32	80
17	900× 600	8	16	32	80
18	1000× 750	9	18	36	90
19	1000× 800	9	18	36	90
20	1000× 1000	10	20	39	96
21	1200× 800		20	39	96
22	1200× 1000		20	39	96
23	1500× 1000		24	48	120
24	1500× 1500		25	50	125
25	2000× 600		24	48	120
26	2000× 1000		26	52	129
27	2000× 1500			56	140
28	2000× 2000			60	152	230
29	2500× 1500			64	152	230
30	2500× 2000			68	168	248
31	2500× 2500			72	180	270
32	3000× 1000				168	248
33	3000× 1500				174	154
34	3000× 2000				184	275
35	3000× 2500				186	276
36	3000× 3000				210	300
37	4000× 1000				210	300
38	4000× 1500				210	300
39	4000× 2000				219	310
40	4000× 2500				228	340
41	4000× 3000				240	360
42	5000× 1500				249	370
43	5000× 2000				255	375
44	5000× 2500				264	390
45	5000× 3000				287	420
46	6000× 2000				293	430
47	6000× 2500				300	450
48	6000× 3000				308	460
49	8000× 2000				370	520
50	8000× 2500				375	530
51	8000× 3000				382	570
ANY SIZE OF CAST IRON SURFACE PLATES CAN BE DESIGNED AND PRODUCED ACCORDING TO CUSTOMER REQUIREMENTS



CAST IRON SURFACE PLATE   DETAILED DESCRIPTION
THE GROSS STRUCTURE OF PLATES IS DIVIDED INTO BOX TYPE AND RIB TYPE. THE SHAPE OF WORKING SURFACE IS RECTANGLE, SQUARE AND ROUNDNESS. ACCORDING TO THE PRECISION MACHINING, IT’ S DIVIDED INTO FINISH PLANE AND SCRAPING. THERE ARE V- SLOTS, T-SLOTS, U-SLOTS, DOVETAIL SLOTS, ROUND HOLES, SLOTTED HOLES ETC CAN BE MACHINED ON THE WORKING SURFACE OF PLATES. THE CAST IRON SURFACE PLATE IS THE BENCHMARK MEASURING TOOL WHICH CAN BE APPLIED TO TESTING, LINEATION, ASSEMBLING, WELDING, INSTALLING AND RIVET WELDING FOR THE WORKPIECES AND EQUIPMENTS. THE CAST IRON SURFACE PLATE ACCESSORIES ARE HAVE ANCHOR BOLTS, ANCHOR DEVICES, LEVELLING BOLTS, T-BOLTS, LEVELLING PAD IRON, COVER PLATE ETC. THE CAST RION SURFACE PLATES CAN BE APPLIED TO WORKPIECES AND EQUIPMENTS INSPECTION APPLICATION, SUCH AS MACHINE TOOLS AND MECHANICAL MEASUREMENT BENCHMARKS, TO TEST THE DIMENSIONAL PRECISION AND FORM AND POSITION DEVIATION FOR THE WORKPIECES, AND TO DO THE PRECISE LINEATION. THE PLATES ARE THE INDISENSABLE TOOLS IN THE MACHINERY MANUFACTURING INDUSTRY. THE WORKING SURFACE HARDNESS IS BETWEEN HB160 AND HB210. THERE ARE TWO TEMPERING TREATMENT (ARTIFICIAL ANNEALING(SEASONING): 600 TO 700 CENTIDEGREE, NATURAL SEASONING: 2 TO 3 YEARS) TO KEEP THE PLATES’ STABILITY AND ABRASION RESISTANCE.
Product Standard	JB/T7974-99, DIN 650 etc.
Specification	200mm*100mm to 3000mm*8000mm
Casting equipment	Cupola Furnace, Industrial Electric Furnace
Casting Technique	Resin Sand Casting etc.
Material	Magnesium iron, Gray iron etc. (such as HT200-300, QT400-700)
Weight	5kg-500000kg
Surface Treatment	Painting, Heat Treatment, Finish Plane etc.
Fine Finishing	Complete machining: Machining center, CNC, Lathe, Milling machine, drilling etc.
Quality Assurance	Physical and Chemical Inspection Report, Metallographic Examination Report, Casting Aging Treatment Report, DIM Inspection Report, Manufacturing Progress Control Schedule, and Customer Requirements Reports. (Third Party inspection available upon customers requirements)
Packaging	Wooden Cases, Steel Cases, Other Export Packaging
Size and design	As per the customer' s drawings and requirements (we can offer the new drawings to the customer)



Enclose:
T-SLOT ACCURACY TO DIN 650
Tolerance on slot width H12. (Tolerance H7 or H8 on request)
Example:
A T-slot DIN 650-28 H12 has a nominal slot opening (a) of 28mm
for bolt size M24(1” ).
The T-slot height (H) according to the table below is 48mm.
(1 mm = 0.03937 inch, 1 inch = 25.4 mm)

Dimension a	For screw		b (mm)	c (mm)	H (mm)	e (mm)
10	M 8	-	17.5 – 18	8	18	1.0
12	M 10	-	20.5 – 21	9	21	1.0
14	M 12	1/2”	23.5 – 24	10	24	1.0
16	M 14	-	26.5 – 27	11	27	1.0
18	M 16	5/8”	29.5 – 30	12	30	1.5
20	M 18	-	33.5 – 34	14	34	1.5
22	M 20	3/4”	37.5 – 38	16	38	1.5
24	M 22	7/8”	41.0 – 42	18	42	1.5
28	M 24	1”	47.0 – 48	20	48	1.5
32	M 27	1 1/8”	54	22	54	1.5
36	M 30	1 1/4”	60	25	61	2.0
42	M 36	1 1/2”	70	29	74	2.0
