| Prod Model: |
GC |
| Markets: |
South America,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia |
| Mode Of Processing: |
Heat Treatment Equipment |
| Heating Device Type: |
Medium/High/Super-Audio Frequency |
Product Description
Induction hardening machine
Introduction:
Induction hardening machine tools are used together with high and medium or super-audio frequency heating devices. For the purpose of conducting heat treatment of work pieces based on their own specificity the hardening equipment falls into: Hardening type, annealing type, tempering type, quenching type, welding and thermoforming type etc.
Hardening machine tools are generally classified as standard and special, the traditional ways are mechanic, hydraulic and compound. The control parts adopt PC control system, ple CNC and PLC system. Which ensure reliable programme running, accurate position, easy operation, high automation. It can improve significantly the hardening quality.
Applycation:
In heat treatment of optic axis, half axis, step axis, varied gears, splined shaft and deformed work pieces. Also in cutter's soldering, annealing and diathermy of metal material as well as in heat treatment of prestressed steel ropes.
| Max holding length (mm) | Max heating diameter (mm) | Weight of the biggest part (kg) | Transmission structure | Cooling method | Main application |
| Vertical hydraulic high frequency hardening machine tools (work piece movement) |
| GC1050 | 500 | 400-600 | 150 | Full hydraulic | Spraying
Immersion | All kinds of axis and gears |
| GC10100 | 1000 |
| GC10150 | 1500 | Spraying |
| GC10200 | 2000 |
| Vertical mechanic high frequency hardening machine tools (work piece movement) |
| Model | Max holding length (mm) | Max heating diameter (mm) | Continuous heating length | Weight of the biggest part (kg) | Transmission structure | Rotary speed of main axis (rpm/min) | Main application |
| GCJK1050 | 500 | 400-600 | 500 | 150
| Full mechanical | 20-150 | All kinds of axis and gears |
| GCJK10100 | 1000 | 1000 |
| GCJK10150 | 1500 | 1500 |
| CNC Vertical hardening machine tools (inductor movement) |
| GCJK1050-CNC | 700 | 400-600 | 500 | 200 | Full mechanical | 1-150 | All kinds of axis and gears |
| GCJK10100-CNC | 1200 | 1000 |
| GCJK10150-CNC | 1700 | 1500 |
| GCJK10200-CNC | 2200 | 2000 |
| Vertical compound medium frequency machine tools (induction movement) |
| GCFW11150/100 | 1500 | 1000 | 1500 | 1500 | Controllable machinery | Cooling method | Axis senes hardening gear Single gear hardening |
| GCFW11150/200 | 2000 |
| GCFW11150/300 | 3000 | 10000 | Spraying
Oil immersion |
| GCFW11150/400 | 2000 | 4000 | 2000 |
| GCFW11150/500 | 5000 | 20000 | spraying |
| GCFW11150/600 | 6000 | spraying |
Tianjin Century Electronics Co., Ltd., was registered in Tianjin Port Free Trade Zone as an independent corporation in August 1997. Since its establishment 10 years ago, the company has shifted from a specialized export enterprise, mainly exporting Chinese power electron devices, to a comprehensive import and export corporation which mainly exports power electron devices, power equipment and complete sets of equipment.
The earliest business can be traced back to 1987 when the company cooperated with some Chinese power electron enterprises for exporting parts of thyristors (ceramic rings and Molybdenum discs) to American market. Through years of tireless efforts, the company has established a wide range of business relations with many famous multinational corporations in relevant fields, and has successfully exported the Chinese power electron devices to more than twenty overseas nations and regions. Moreover, there are nearly twenty distributors and agents all around the world. At present, the company is making effort to export different kinds of power equipment, including the whole sets of equipment used for manufacturing power electron devices, solar generator system, wind generator system, uninterruptible power supply (UPS), industrial electric heating equipment, set welding equipment, industrial automation equipment and switch equipment and etc.
The company has been acknowledged by the accreditation of Standard ISO9001: 2000 of Quality Management System in 2002, and it completed the certification of Credit China System. The company also serves as the Director of Power Electronics Society under China Electrical Equipment Industry Association. Furthermore, the company has been entitled to the Working Committee on International Trade of China Power Supply Special Committee of CECC. The working committee will assume the responsibilities of pushing the Chinese enterprises to stride to the international market.
Meanwhile the corporation is engaging in developing the import business, assisting the Chinese enterprises to bring in the advanced technology from overseas markets and purchase the set equipment and raw materials. On the other hand, with great effort, the company will spur the foreign companies to access to Chinese market, promoting the collaboration between Chinese and foreign enterprises in the filed of investment and technological transfer.
