Hitachi Zx650 Excavator Hydraulic Bucket/Boom/Arm Cylinder

Hitachi Zx650 Excavator Hydraulic Bucket/Boom/Arm Cylinder
Price: US $ 3500-3800/Piece
Trade Terms: FOB,EXW
Min Order: 1/Piece
Pay Type: L/C,T/T,Western Union
Prod Model: ZX650
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Color: Can Be Customized
Coating: Hard Chromium/Nickel Plated /Ceramic
Seal Kit: Genuine Nok / Merkel / Hallite/Parkin
Working Pressure: 32mpa
Fluid: Mineral Oil
Max Stroke: 4000mm
Piston Speed: Max 0.5m/S
Mounting Style: Optional
Technology: German Bosch Rexroth
Body Material: #45 Steel
Standard: Standard
Power: Hydraulic
Structure: Piston Cylinder
Pressure Direction: Double-acting Cylinder
Material: Steel

Product Description

Hitachi ZX650 Excavator Hydraulic Bucket/boom/arm Cylinder


CATSU Hydraulic Co., Ltd, a hydraulic cylinder OEM in China with a 90, 000 m² Factory. We are in the market for over 25 years, Catsu is certified by ISO9001: 2008, specialized in excavator cylinders and super-large super-long custom hydraulic cylinders with high quality and competitive price. We also have our own professional designers to meet any of your requirements.




1. PRODUCT DESCRIPTION

1. Max stroke length: 25000 mm
Working pressure: 16---36 mpa
Max bore diameter: 200---2000 mm
Piston rod diameter: 150---1480 mm
2. Product material: Steel 45#
3. Seal kits: Merkel, Nok, Perker, Hallite
4.1 year guarantee
5. Mounting type: Optional mounting style --- plain clevis at base / self-aliging clevis at base /round flange at head or base/tunnions /foot mounting
6. Iron carton/wood shelf /plywood carton for the packing



2. OEM CUSTOM DESIGN

1) end cushioning
2) integrated displacement
3) integrated proximity switches
4) valve mounting faces
5) flanged cover/bottom construction
6) complete 45 steel design
7) high temperature seals VITON
8) low friction seals



3. FACTORY PROFILE

Catsu is one of the largest and most professional hydraulic cylinder manufacturer in China. We own an over 90, 000 square meters modern standard factory, and more than 220 sets of state-of-the-art large digital equipment, ball rolling machines, honing machines, CNC, Boring machine, lathe, cutting machine, welding machine, auto welding robot, sand blast, painting etc.
1. Production capacity: 1000 pcs/month
2. Factory area: 90000 square meters
3. Machines: 220 sets
4. Professional design team and technical department
5. Strict quality control for each production step



4. ASK FOR A QUOTATION


We also make custom cylinders according to your requirements. More than 78% of our orders are custom-made and newly designed. To get an immediate quotation, please provide us with the following necessary parameters:
1) Bore diameter (mm)
2) piston rod diameter (mm)
3) stroke (mm)
4) working pressure
5) front and back end mounting method ( spherical bearing clevis, female or male clevis, foot mounted, flange, trunnion etc. )
                          Model  No.                    Cylinder
    Name
diameter
   (mm)
    rod  diameter  mm stroke  (mm) assembly   distance
(mm)
working   pressure
(mpa)
connection
      form
CT-A120-G30 bucket cylinder      95        65    885   1378      32.5 two ends ear ring bushing block
CT-A120-G11 boom cylinder     105        70    980   1500
CT-A120-G20 arm cylinder     115        75    1175   1702
CT-A200-G20 arm cylinder     130        95    1473    2049
CT-A220-G30 bucket cylinder     130        90    1020    1605
CT-A220-G20 arm cylinder     140       100    1635     2235
CT-A220-G12 boom cylinder     150       105    1510     2150
CT-A300-G20 arm cylinder     170        115    1796     2475
CT-A400-G20 arm cylinder     190        130    1928     2632
CT-A700-G20 arm cylinder      215        150    2175     3080





















Brand Excavator Model
Hitachi EX1200, EX1100, EX800, EX750, EX700, EX600, EX550, EX400
EX300, EX200, EX120
ZX870, ZX850, ZX800, ZX650, ZX450, ZX350, ZX330, ZX270,
ZX240, ZX230, ZX210, ZX200, ZX120
Komatsu PC5500, PC5000, PC4000, PC3500, PC3000, PC2000, PC1250, PC1100, PC800
PC750, PC600, PC450, PC400, PC350, PC300, PC270, PC200, PC120
Kobelco SK480, SK450, SK350, SK330, SK320, SK230, SK200, E135SR, SK120
Vol EC700, EC460, EC360, EC290, EC210
other brands TEREX(RH170), Liebherr, KATO














Name Description
Barrel Seamless forged tube
Base Welded, screwed, bolts, tie rod
Head Connected by threading, bolts, tie rod
Piston Machined with grooves, can be single acting or double acting
Piston rod hard chrome plated, cold rolled steel
Seals Hallite, NOK, Parker, Merkel
Catsu hydraulic is a leading cylinder manufacturer in China, we are the member of China Hydraulic Industry association and Engineering Machinery Association. We specialize in the design, manufacture super large & long, high requirements & high anticorrosion hydraulic cylinder, spillway(dam) radial gate hydrauli c cylinder, Servo hydraulic cylinder, cylinders Including marine & offshore, Offshore Oil & Gas equipments, Smelters(steel factory), metallurgy, mining, engineering machinery equipment, water conservancy facilities, pressure machines, manifold blocks and hydraulic power system units.

After years of developing, our company start from a small workshop, right now we have become a large and famous hydraulic cylinder manufacturer, we have over 65000 square meters modern standard factory, have more than 270 sets of modern big digital equipments, such as ball rolling machines, honing machines, CNC, Boring machine, lathe, cutting machine, welding machine, auto welding robot, shot blast room, paiting roon and so on.

The rod we can plate hard chrome, nickel or Ceramic coating. The seals we import from the famous brands: NOK, Hallite, Merkel

Our Capacity: Maximal bore: 2000mm, Maximal Stroke: 20meters, maximal weight: 110 ton/PC, maximal pressure can up to 160Mpa.

Honest, Innovation, High quality, competitive price are our core purpose, once cooperation, friend forever. Friends and customers are welcome to our facility anytime.

We make the Hydraulic World!
