| Prod Model: |
Z42-500X400X300mm |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Guarantee Period: |
One Year |
| Easy Wear Parts: |
We Always Sale |
| Customization: |
Design by Your Mean |
| Certificate: |
ISO,BV,SGS |
| Automation: |
Automatic |
| Structure: |
Horizontal |
| Computerized: |
Computerized |
| Type: |
Injection Compaction Molding for Foundry |
| Plastic Type: |
Iron Water |
Product Description
USE
The casting machine is used to make green sand mold for casting.
MECHANISM
It use compressed air shoot sand evenly into the sand box to preliminary compact,and then exert pressure for compaction.After making sand mould, get mould assembly and take off sand box. So setting core is convenient, capacity is big.
FEATURES
1. Used for the production of auto parts, such as cylinder head, flywheel shell, brake pliers, etc.
2. Suitable for tube class parts, valve class parts , axial, cover parts,as direct, tee,elbow, pipe clamp
3. Suitable for the manual molding to automation transformation.
4. We could equip with convey machine,pouring machine to inform whole molding line
COPMANY,Intial public offerings in Shenzhen stock exchange of China.
|
Parameter |
|
Z42-450*350 |
Z42-500*400 |
Z42-600*500 |
|
Sand mold size |
mm |
450*350*150/150 450*350*120/120 |
500*400*150/150 |
600*500*150/150 |
|
Add sand way |
|
shot sand pneumatically |
shot sand pneumatically |
shot sand pneumatically |
|
Tight sand way |
|
compaction hydraulic |
compaction hydraulic |
compaction hydraulic |
|
Compaction pressure |
Mpa |
0.52-0.6 |
0.52-0.6 |
0.52-0.6 |
|
Capacity |
|
90mold/h ,no core setting |
90mold/h ,no core setting |
90mold/h ,no core setting |
