Product Description
JM31 / JMD31 series gantry type single point punch
Punching machine features:
Steel plate welded framework structure machine body with four masts to ensure the high strength of the machine body
Imported dry-type friction clutch, and wet-type clutch optional for JM31-160~400
Hydraulic overload protection device, imported pneumatic pump, imported sealing ring
Steel plate welded slide clock
Four-corner eight- side precision long guideway
Electrical die adjustment, digital display
Raising-up balance cylinder, imported from Japan
Tow interlinked pieces for air source imported from abroad
PLC of international brand name
Buttons, indicators, AC contactors, air switched and other control devices imported from abroad
Imported transducer of international brand is optional, whitch can realize number of stroke adjustable
Series JMD31 equipped with link structure, making it more fitted to superficial stretch process
Press machine specifications:
|
model |
JC31M-250 JD31M-250 |
JC31M-400 JD31M-400 |
JC31M-500 JD31M-500 |
JC31M-630 JD31M-630 |
JC31M-800 JD31M-800 |
|
nominal force |
kn |
2500 |
4000 |
5000 |
6300 |
8000 |
|
stroke under nominal force |
mm |
11 |
13 |
13 |
13 |
13 |
|
slide block stroke |
mm |
315 |
400 |
400 |
400 |
500 |
|
number of stroke |
spm |
20 |
20 |
18 |
12 |
10 |
|
max die set height |
mm |
500 |
600 |
700 |
700 |
800 |
|
die set height adjustment |
mm |
250 |
250 |
250 |
250 |
315 |
|
worktable dimensions (f.b*l.r*h) |
mm |
950*100*160 |
1200*1240*180 |
1400*1500*200 |
1500*1700*200 |
1600*1900*210 |
|
dimensions of slide block (f.b*l.r) |
mm |
850*960 |
1100*1250 |
1350*1500 |
1400*1700 |
1500*1800 |
|
stroke of materials to be punched (rigid) |
mm |
100 |
150 |
150 |
150 |
200 |
|
distance between gibs |
mm |
800 |
1150 |
1350 |
1600 |
1800 |
|
cushion (option) |
ejection force |
kn |
250 |
400 |
500 |
500 |
800 |
|
stroke |
mm |
150 |
200 |
200 |
200 |
250 |
|
main motor power |
kg |
30 |
45 |
55 |
45 |
75 |
