| Prod Model: |
AF-M240 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Name: |
Large Span Roll Forming Machinery |
| Machine Size: |
11m*1.4m*2.3m |
| Machine Color: |
According to Your Requirement |
| Machine Weight: |
10 Tons |
| Delivery Time: |
40 Working Days |
| Material Feeding Width: |
914mm |
| Material Effective Width: |
610mm |
| Material Thickness: |
0.8-1.5mm |
| Size Of Container: |
40gp |
| Usage: |
Roof and Wall |
| Forging Forming Method: |
Mold Forging |
Product Description
Large span roll forming machinery
Brief Description
Roll forming machine
Large Span roll forming machine(MIC240): Max span: 38m
Large Span roll forming machine(MIC120): Max span: 24m
Product Attributes
Related attributes of K Span Roll Forming Machine:
Place of Origin: Shanghai China (Mainland)
Brand Name: AF
Model Number: 120/240
Size of mic240: 9300mmx2270mmx2530mm
Size of mic120: 7400mmx2050mmx2000mm
Max span mic240: 38m
Max span mic120: 24m
Color: All on your demand
Detailed Description
Detailed introduction to K Span Roll Forming Machine:
Roll forming machine
Roll forming machine
We are professional roll forming machine manufacturer, we offer the best machines with reasonable price
The products from roll forming machine looks very beautiful and have a high strength, its widely used as the roof of the factory, garden, hotel, exhibition
Main Technical Specification (mic240)
1. Size: 9300mmx2270mmx2530mm
2. Total Weight: About 12000kg
3. Controlling System: PLC
4. Forming Power: 7.5kw
5. Bending Power: 4.0kw+1.1kw+1.1kw
6. Cutting Power: 3.0kw
7. Material of rollers: 45#steel, quenched HRC 58-62
8. Material of roller shafts: 45#steel
9. Material of cutting blade: Cr12 steel
10. PLC Type: Siemens
11. Step of rollers: 13 steps
12. Feeding Width: 914mm
13. Effective Width: 610mm
14. Thickness of the coil: 0.6-1.6mm
15. The depth of the groove: 203mm
16. Working speed: Straight sheet: 15m/min
17. Arch sheet: 13m/min
18. Sewing: 10m/min
19. Max span: 38m
Main Technical Specification (mic120)
1. Size: 7400mm X2050mm X 2000mm
2. Total Weight: About 9000kg
3. Controlling system: PLC
4. Main forming unit driving motor power: 7.5kw
5. Curving motor power: 4+1.1+1.1
6. Electric cutting power: 3kw
7. Material of roller: 45#steel, quenched HRC58-62
8. Material of roller shafts: 45#steel, adjusted
9. Material of cutting blade: Cr12
10. Step of rollers: 13 steps
11. Feeding Width: 600mm
12. Effective Width: 305mm
13. The depth of the groove: 109mm
14. Thickness of the coil: 0.6-1.5mm
15. Working speed: Straight sheet: 15m/min
16. Arch sheet: 13m/min
17. Sewing: 10m/min
18. Max span: 24m
Features of our AF-roll forming machine
1. All the rollers are forged form the high quality structural steel and are processed intensely. The surfaces of the rollers are plated with hard chromium. The rollers have a high hardness and long operating life
2. The power set to automatically transport the colored steel sheet is equipped in the forming press section which can press the colored steel sheet with the thickness of 0.6-1.6. It is not needed to frequently adjust the clearance between the pressing rolls when pressing the sheet with different thickness which can make the sheet come out from machine is very simple. But the quality of the finished product can be guaranteed
3. The length of the finished sheet is measured by the electronic measurement instrument or mechanical measurement instrument. The helping hand wheel and the counter are used in the adjustment of the bending of arch sheet, which makes the operation simple and guarantees the quality and the dimensional precision
4. The hoisting tool is light and handy (The weight of hoisting tool of the United States is 30KG. And the weight of hoisting tool of our company is 2KG) It is convenient to install and uninstall the hoisting tool, its hoisting speed is quick
We mainly supply high quality roll forming machine. We have achieved good performance up to now, sincerely welcome businessmen overseas to establish a long-term cooperation to create a beautiful tomorrow!
Our factory mainly produce all kinds of roll forming machine, for example, rofo sheet roll forming machine, c purlin roll forming machine, glazed tile roll forming machine, deck floor roll forming machine, sandwich panel production line and so on.
Our factory is established form 2010, up to now, we have sold machines to Canada, Bolivia, South Africa, Dubai, India, Russia and many other countries,
Hope we can cooperate happily
