Low Pressure Die Casting Machine

Low Pressure Die Casting Machine
Price: Negotiable/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,Money Gram,Western Union
Prod Model: JS452
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe

Product Description

Structural performance of products casted by low pressure die-casting machine is better than that of products casted by cold chamber high pressure die-casting machine
Temperature of molten aluminum is automatically controlled by high accuracy intelligent temperature controller.
Pressure self-compensation function and accurate pressure control in the die-casting process.
Automatic pressure maintaining, pressure relief, and auto-cooling function available.
Compared to products casted by other ordinary low pressure die-casting machine, high pressure & pressure maintaining function of this model makes finer metallographic structure & stronger mechanical property of products.
Big die-filling area, convenient die-filling, safe operation, fast mould position, installation time significantly shortened.
Small floor area, easy technical operation.
Simple mechanism, reliable operation, highly cost effective.
The machine could manufacture different kinds of aluminum alloy products: electric power fittings, gearbox shell, fan impeller, hydraulic couplers, automobile hub, cylinders, motorcycle cylinder head, damper, fluid pump, brake pump, valve, etc
No.Parameter nameUnitValueNo.Parameter nameUnitValue
1Capacity of holding furnacekg20011Ejector die plate strokemm450
2Power of holding furnacekw3012Hydraulic motor powerkw5.5
3Size of control cabinetmm1270×900×69013Hydraulic working powermpa6
4Outline size of machinemm4007×3200×125014Hydraulic oil type#46
5Size of holding furnacemmΦ1150×138015Diameter of opening cylinderΦ150
6Min opening heightmm45016Diameter of core cylinderΦ125
7Max opening heightmm90017Core cylinder center heightmm150
8Guide the column spacingmm975*77518Core-pulling strokemm300
9The total weight equipmentt5.519Min core-pulling gapmm400
10Working time of core cylinders3.7~4.720Max core-pulling gapmm1000
Founded in 1999, CEA Group International Co., Ltd.Is being acknowledged as one of the most respected nationwide manufacturers and exporters of low voltage electrical apparatus in P.R of China.

The Group, comprising 5 factories, owns a production area of 50, 000m2 and employs more than 1, 000 staff.During the past 13 years, we invested abundant resources in both research and development and employee training programs.The company was ranked in the front of 100 tops of wenzhou private enterprises." CEA" is named as a famous trademark in domestic and overseas markets.Our company has took the lead in applying IS09001 Quality Management System and ISO14001 Environmenttal Management System.Many products are certified under international certificate, such as CB, CE, BS, VDE, UL, SONCAP, CCC.

Currently, we have manufactured and exported more than 160 varieties of products, with over 2000 types of low voltage electrical apparatus including all kinds of LED lighting, Circuit Breakers, Contactors, Relays, Starters, Switches, , Wire & Cable and Electrical Accessories etc.As a result of our high quality products and outstanding customer service, we have gained a global sales network reaching South East Asia, Middle East, South America, Africa, Europe.

We are fully aware of the fact that only "Versatile Staff, Distinctive Quality and Advanced Technology"enable us to survive and succeed in today's intensively competitive market.Hence, we will be with overall technology support, good service to meet the requirements of world.

Enquiries from both domestic and overseas customers are cordially welcomed.Just Tell Us Your Requirements and Let Us Do The Rest For You!
