Specifications
Swing over bed 210 mm
Distance between centers 410 mm
Hole through spindle 20 mm
Spindle taper MT3
Tailstock taper MT2
Spindle speed 150-2000 rpm±10%
Compound travel 70 mm
Cross slide travel 100 mm
Motor output power 1000 W
Thread range Metric 0.25-3.0 mm
and Inch 8-24 TPI
Overall dimension (LxWxH) 1000x550x400 mm
Weight (Net/Gross) 94/125 kg
Packing Size (LxWxH) 1070x710x530 mm
Beili Industry Co., Limited (Beili) is a private owned exporter. We mainly supply all kinds of high quality metal-working machine tools and surveying instruments in China.
Total station, , Electronic Theodolite, Laser Theodolite, Distance Meter, Auto level, Surveying accessories, such as single prism set (leica, Sokkia) three prism set(leica, Sokkia) and so on.
If you are interested in our products or you have any inquiries, please kindly let us know without any delay by telephone/fax/e-mail. Hope we can serve you in the near future.
