Motor Direct Driven Blasting Wheel Turbines/Impeller Head /Impeller Unit - 7.5kw (HQ034)
| Price: |
Negotiable |
| Trade Terms: |
FOB |
| Min Order: |
1set |
| Pay Type: |
T/T |
| Prod Model: |
HQ034 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Deformation Temperature: |
Isothermal Forging |
| Molding Style: |
Forging |
| Molding Technics: |
Gravity Casting |
| Casting Method: |
Special Casting |
Product Description
Blast wheel Turbines
This is the key device of shot blasting machine, blasting steel shot to clean the surface of metal parts. The clean effect is based on the efficiency of the blasting wheel turbines
The blast wheel is the most important part of the shot blasting machine, where it is rotate by the motor. Abrasive particles are projected by centrifugal force from various kinds of turbine wheels. The number of wheels installed in the machine depends on the type of jobs to be shot blasted and the rate of work. The wheel is the heart of every centrifugal shot-blasting machine. Efficiency and cleaning effect depend to a great extent on the quality of the wheel and its components.
Our blasting wheel turbines is with high efficiency, compact design and widely used for the shot blasting machine industry.
We have special crafts on hot treating and wear-resisting parts, which can supply varies of wear-castings, including blade, control cage, impeller, guard board etc. We provide high quality abrasion-resistant fittings on demand of customers and complying with the standards and requirements of the country where the machines are used. Our proof wear-resisting parts have received the good comment from home and abroad. We also produce the products which can replace the spare parts needing import in our homeland.
Our company has be granted CE, ISO9001 and SGS etc.
Our products are sold to throughout China and exported to many countries, like Australia, Bulgaria, India, Russia, Turkey, Vietnam, Mexico, Czech, Holand, Finland, Iran, Philippines, Indonesia etc.
The HQ03 series of blast wheels have the following type:
HQ034I, II, III A (5.5, 7.5, 11, 15, 18.5KW) direct centrifugal blast wheels
HQ034I, II, III B(11, 15, 18.5KW) belt driven centrifugal blast wheels
HQ035I, II (18.5, 22KW) belt driven centrifugal blast wheels
HQ036I, II (22, 30KW) belt driven curve blade centrifugal blast wheels
Notice:
1. Q034A and Q034B is two different blast wheels.
2. All the Q034B centrifugal blast wheels adopts B series narrow V type belts
Special design based on the requirements of customer is available.
With professional test equipment in our company, we can test electric system and parts in various voltage and Hertz worldwide, the test range is 0-600V, 45-60Hz, passed the test, it can ensure our machine working normally under specific power at the user side.
|
Model |
Diameter. of the blade size (mm) |
The width of the blade (mm) |
The speed of the impeller (r/min) |
Shot velocity (m/s) |
Shot amount (kg/min) |
Motor type |
Motor power KW |
Belt QTY |
BladeQTY |
|
HQ034 |
380 |
62 |
2900 |
63 |
100 |
C180M |
5.5 |
|
8 |
|
HQ034I |
400 |
80 |
2930 |
73 |
120 |
C180M |
7.5 |
|
8 |
|
HQ034II A |
420 |
80 |
2930 |
74 |
180 |
C180M |
11 |
|
8 |
|
HQ034III A |
420 |
80 |
2930 |
74 |
250 |
C180M |
15 |
|
8 |
|
HQ034III A |
420 |
80 |
2930 |
74 |
320 |
C180M |
18.5 |
|
8 |
|
HQ034II B |
420 |
80 |
2930 |
74 |
180 |
C180M |
11 |
6 |
8 |
|
HQ034III B |
420 |
80 |
2930 |
74 |
250 |
C180M |
15 |
6 |
8 |
|
HQ034III B |
420 |
80 |
2930 |
76 |
320 |
C180M |
18.5 |
6 |
8 |
|
HQ035I |
450 |
100 |
2940 |
78 |
320 |
C180M |
18.5 |
6 |
8 |
|
HQ035II |
450 |
100 |
2940 |
78 |
350 |
C180M |
22 |
4 |
8 |
|
HQ036I |
492 |
100 |
2600 |
78 |
350 |
C180M |
22 |
4 |
8 |
|
HQ036II |
492 |
100 |
2600 |
78 |
360 |
C180M |
30 |
4 |
8 |
Established in 2005, as a growing factory located in dafeng city, jiangsu province, we, Yancheng C&J Machinery Co., Ltd. is specialized in manufacturing all kinds of surface grinders machine and shot blast cleaning machines for many years. Also we can supply all kinds of lathe machine, milling machine, driling machine and sawing machine, shearing machine, press brake and so on other machine tools based on customer's requirement.
With high quanlity and competitve price & rapid delivery time our goods have been popular in every country. Our goods has been mainly exported to USA and Europe and other Asia, south America countries, especially, Vietnam, Brazil, Argentina. Poland, Turkey and so on.
In our company we have many professional technicians specialized in design, manufacture, inspection and after-sales services of our grinding machine.
Also quanlity assurance has been always the key secret of our success. Every single machine is thoroughly tested under load before delivery the customers. And we provide one-year parts warrantly to our customers around the world as well as professional technical support and services.
With the sprite of "quality first, user supreme", we're insisting on seeking survival with quanlity, to seek the development with reputation, to compete by technology, with the management concept of taking customer as god, we provide best quality with best price to our overseas buyerand we will forever do our best to proceed and gain further sucess. Your demand is our pursuit forever. We are ready to establish mutual benefits with companies both at home and abroad. If you are interested in any of our products, please feel free to contact us immediately.
At present our main products range as following:
Surface grinding machine
Manual Surface grinder: M618A, M820, M250
Auto electric Surface grinder: MD618A, MD820, MD250
Auto Hydraulic Surface grinder: MY618, MY820, MY250, MY3060, MY3075, M230A, M7125A, M7135A, M7140A
Full Auto (PLC) hydraulic Surface grinder: SG2050AHD, SGA2550AHD, SGA3063AHD, SGA4080AHD, SGA40100AHD
Wheel Head Moving Surface grinder: M7130, M7132, M7140, M7150, M7160, M7163
Full Auto PLC Column moving surface grinder: SG50100AHD, SG50160AHD, SG60120AHD, SG60160AHD, SG60220AHD, SG50100SD, SG50160SD, SG60120SD, SG60160SD, SG60220SD,
Cylindrical grinding machine (MW1320, M1332, M1350, M1363, M1380), Universal cylindrical grinding machine M1420, MW1420, M1432B, M1450, M1463) and so on.
Shot blast cleaning machine
- Q31 Rotary barrel( drum) type shot blast cleaning machine
- Q32 Tumblast type shot blast cleaning machine
Q324, Q326, Q328, Q3210 tumble rubber belt shot blasting machine
Q3210 Auto loading tumble shot blasting machine
- Q35 Turn table type shot blasting machine
- Q36 series car type shot blasting machine
- Q38/48/58 series hanging chain type shot blasting machine
- Q76 series car type shot blasting machine
- Q37 Spinner Hook tpye shot blast cleaning machine
- Internal & external pipe series shot blasting machine
- Q69 Roller type pass through shot blast cleaning machine
Q69 series Steelplate/profile series shot blasting machine (horizontal)
QH- Section/H-Bean structural steel series shot blasting machine ( Vertical)
- Steel plate pretreatment line
- Air recycling type/ Mechanical recycling shot peeing machine
- Internal & external pipe series shot blasting machine
- Big Sand Blasting room
- Blasting coating production line
- Sand blasting machine
- Dust collector (pleated bag with vibrating mechanism, cartridge filter with pulse valve)
- Blast wheels(impellers), shot blasting turbines system
( motor direct driven or belt driven 5.5kw, 7.5kw, 11kw, 15kw, 18.5kw, 22kw, 30kw, 75kw ),
- All kinds of spare parts
-blades, control cage, impeller, wheel hub, end liner, top liner, side liner, chamber liner.
