| Prod Model: |
RV Series |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model: |
Nmrv030-150 |
| Ratio: |
7.5, 10, 15, 20, 25, 30, 40, 50, 60, 80 |
| Color: |
Blue, Silver or Customer Request |
| Material: |
Housing-Casting Iron-Ht 200# (Aluminum) |
| Seal: |
Nak Seal From Taiwan |
| Lubricant: |
Synthetic Oil or Mineral Oil |
| Type: |
Worm and Wormwheel |
| Manufacturing Method: |
Cast Gear |
| Toothed Portion Shape: |
Spur Gear |
Product Description
Type: Worm Gear Speed Reducer
Model: NMRV030-150
Ratio: 1: 7.5, 10, 15, 20, 25, 30, 40, 50, 60, 80
Color: Blue/Silver Or Customer Request
Material: Housing-Casting Iron-HT 200# (Aluminum)
Worm Gear-Cooper-10-1#
Worm- 20CrMn Ti with carburizing and quenching, surface harness is 56-62HRC
Shaft-chromium steel-45#
Packing: Carton and Wooden Case
Bearing: Chinese Famous Brand Bearing
Seal: NAK Seal from Taiwan
Warranty: 1 Year
Input Power: 0.06Kw 0.09KW 0.12Kw 0.18Kw
Usages: Industrial Machine: Food Stuff, Ceramics, CHEMICAL, Packing, Dyeing, Woodworking, Glass...
IEC Flange: 80B5, 90B5, 100B5, 112B5, 132B5
Lubricant: Synthetic Oil Or Mineral Oil
|
Type: |
Motovario Worm Gearbox |
|
Model: |
Center Distance:25,30,40,50,63,75,90,110,130 |
|
Ratio: |
5,7.5,10,15,20,25,30,40,50,60,80,100 |
|
Color: |
Blue/Silver White |
|
Packing: |
Corton box |
|
Warranty: |
1 years |
|
Useage: |
In industrial machine: widely used in packing, printing
textile machine,as well as woodworking,glass and plastics,food stuff,ceramics,chemical,etc. |
|
NMRV-063-30-VS-F1(FA)-AS-80B5-0.55KW-B3 |
|
NMRV |
Hole-input with flange |
|
NRV |
Shaft-input without flange |
|
063 |
Centre Distance |
|
30 |
Ratio |
|
VS |
Double input shaft |
F1(FA) |
Output Flange |
|
AS |
Single output shaft |
AB |
Double output shaft |
|
PAM |
Fitted For Motor |
80B5 |
Motor mounting facility |
|
0.55KW |
Motor Power |
B3 |
Mounting position |
Hangzhou Nayuan Transmission machinery Co., Ltd is a professional enterprise which has gotten scientific research, manufacture and sale service together in drive equipment field.
We have advanced production equipment and prefect test method, for years, our product have been on sale many cities and exported to the USA and other counties.
We develop new product constantly, at present, we have many types and specifications reduction machine as worm and gear, worm gear screw jack, stepless speed change type and etc, provide correlative brackets and shaft couplings and other correlative product. We have built up rich experience in making non-standard drive products.
The NaYuan products have used widely in many industries and fields, asbrewing and beverage industry, foodstuff and package industry, textile and dye printing industry, rubber and plastic industry, oil and chemical industry, crane and transportation, environmental equipment, etc.
There isn't best but better only. Nayuan company will not stop the progressive step forever, wish nayuan company become your friend and partner and create a fine prospect togther.
