| Prod Model: |
Cr12MOV |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
as Per Drawings |
| Shape: |
Round or Plate |
| Processing Object: |
Metal |
| Molding Style: |
Forging |
| Heat Treatment: |
Normalizing+Annealing+Quenching+Tempering |
Product Description
Product Details:| Material | Cr12MoV (Chemical Compositions %) |
| C Si Mn Cr Mo V P & S |
| 1.40-1.70 ≤0.40 ≤0.40 11.00-12.50 0.40-0.60 0.15-0.30 ≤0.030 |
| Size | Round φ20-650mm; Flat 20-450x50-810mm |
| Origin Place | Made in China |
| Delivery Condition | Forged/hot rolled |
| Surface Treatment | Black/grinded/peeled/turned/milled/polish/bright |
| Heat Treatment | Annealed 2-4 times |
| Packing | Seaworthy packing or as per client's request |
| MOQ | 10Ton |
| Delivery Time | EXW 25-60 Days |
| Trade Term | FOB/CIF/CFR |
| Payment Term | T/T or L/C at sight or DP at sight |
| Loading Port | Ningbo/Shanghai/other ports as per client's request |
Heat Treatment:Forge: At 1020° C-1040° C Cool slowly and anneal immediatelyAnnealing: At 650° C-850° C Cool slowly in furnaceStress Relieving: At 650° C Cool slowly to 500° C, then freely in airHardening: Preheat at 650° C-750° C raise to 1020° C-1050° C Cool in air, oil or into salt bath held at 500° C-550° C and then air cool.APPLICATIONS: Used for metal stamping die, drawing die, stainless steel sheet blanking die, blanking die with high hardness, shearContact
We warmly welcome clients from all over the world to cooperate with us and develop
worldwide market together. Also we hope we can have chance to establish longterm
business relationship with you on the basis of mutual benefit.
Hongfeng can provide the products with the single weight up to 11mt and diameter up to 3m, such as tube sheets, rings, cylinder and shafts, etc. The material includes Austenitic stainless steel, Martensitic stainless steel, Duplex Stainless Steel, Carbon steel and Alloy steel. Their products widely used in transmission, mould, metallurgy, petrochemical, valve, shipbuilding, and cars. Our company has more than 18years experience, with the ability to provide a series service of blanking, heating, forging, heat-treatment, CNC, inspection, surface-treatment, packing and shipping.
Since establishment, Hongfeng develops year by year; The main equipments are as below: 1 set for each 11mt & 5mt electro-hydraulic hammers, 1set for each 3mt, 1.5mt, 1mt and 750kgs air hammers; 5 sets of gas heat furnaces; 3sets of electrical heat treatment furnaces; 2 sets for each 16mt&10mt and 4sets of 5mt cranes; 5 sets of Large sawing machines ( the sawing length up to 3m), 12sets of common sawing machines; 4sets of vertical lathes(¢ 3m*2.5m), 3sets of 10m*¢ 1.4 and 8sets of 1m*¢ 800mm horizontal lathes. The production capacity can reach 20000mt; The products are strictly according to the standard. From the beginning to the end of every order, we have detailed records for every process.
