| Prod Model: |
NAK80 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Grade: |
Nak80 |
| Condition: |
Forged |
| Surface: |
Machined Surface |
| Place Of Origin: |
China |
| Certification: |
ISO9001:2008;SGS Test;Mtc |
| Packaging Details: |
Raw Packing or According to Customer's Requirement |
| Payment: |
30%Deposit. The Blance Against L/C at Sight or T/T |
| Hardness: |
38~42HRC |
| MOQ: |
5 Tons |
| Delivery Time: |
7-15 Days |
| Standard: |
GB |
Product Description
NAK80 Forging Steel
NAK80 Forging Steel / steel bar / forging steel plate / forging mould steel / mould steel / forging steel plate
1. Forged condition, Pre-harden & tempering, milled surface
2. Hardness: 38~42HRC
3. Forged technology: EAF+LF+VD+ESR+Forging +Q T + Machined surface
4. Production leadtime: 7~15 days
5. Ultrasonic test standard: SPE1921-GR3, CLASS E/E
Applications:
· Used for high-grade mirror mold (Molds for transparent, e. G. Cosmetics containers, food containers and daily electrical appliances. )
· Used for the mold focusing on discharge machining surface, (Molds for such products as fruit plate, food box, computer casing, keyboards and automobile interior decorations)
Used for plastic molds under long production at high precision. (Molds for such products as electrical switches, multifunctional sockets, plugs, charger cashing and computer parts. )
Competitive Advantage:
1. Good workability and mirror polishing property, suitable for thermoset molding of general resin
2. Material is a steel smelted by using refining degassing and ESP remelting, suitable for super-mirror molds with high polishing property requirements.
3. Stable hardness after electric spark machining, easy to repair and Polish the mold
4. Competitive price
5. Fast production leadtime
6. All the material are inspected with 3 times to meet the highly standards material supplied
|
|
Steel plate(mm) |
Mill name |
|
|
Thickness |
Width |
Length |
|
|
Forged condition |
120 ~ 800 |
335 ~1200 |
2500~4000 |
Local mill with 6000tons fluid forged machine |
Chemical composition:
|
C |
Si |
Mn |
Ni |
Cu |
Mo |
Al |
P&S |
Cr |
|
0.1-0.15 |
0.15-1.0 |
1.0-2.0 |
2.50-3.50 |
0.70-1.50 |
0.10-0.40 |
0.7~1.1 |
≤0.03 |
≤0.05 |
DongGuan RuiYuan Steel Co., Ltd is a leading company of supply plastic die steel, hot work steel, cold work steel, alloy structural steel, bearing steel, high speed tool steel, carbon steel, stainless steel and so on with different kinds of steel, we are begin to export the steel material from 2008 with fully export working experience to the market all over the world, such as Middle-East, Brazil, Poland, Turkey, Singapore, Malaysia, India, Italy, Korea and so on.
RuiYuan Steel focuses on special steel industry over many years, we has established reliable and stable sourcing with over 40 mills and manufacturers in China, Our company have introduced large-sized Vertical saw machines, Horizontal saw machines, Milling machines, Grinding machines and other advance equipments, we can export our products by wholesales and retail sales, it can sale of whole plate or strip, all our products can meet the standards of DIN, AISI, JIS and GB, all the material should be inspected the ultrasonic, hardness and others strict inspection process before the shipment! We hope to cooperate with the customers from different countries, shares its experiences and develops with the world together.
Our company keeps the principle of "reputation is fisrt, customer is our god". We sincerely provide high quality, competitive price and quickly delivery to serve our valued customer, we desire to establish the mutual beneficial and long-term relation with importers from all over the world, please feel free to contact us and welcome you to visit our company!
