| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Package: |
Manmade Wooden Case or Pallet |
| Certificate: |
ISO 9001 |
| Production Capability: |
150ton/Month |
| Origin Place: |
Qingdao China |
| Brand: |
Chifine |
| Surface Treatment: |
Die Casting |
| Delivery Time: |
30 Days After Receiving The Payment |
| Material: |
Aluminum |
| Surface Preparation: |
Polishing |
| Machining: |
CNC Machining,Turning ,Milling ,Drilling, Lathe |
Product Description
-Customized Tool Design Drawings are Available;
-Molds are carefully machined to the closest tolerance using the latest equipment;
-The prototype should be created if the customer require;
-We offer secondary processing such as oil spraying, screen printing, assembly ect.
-Traceability is maintained from all inspection gages
-Mold repair and maintenance are also supported internally.
Molding process---die casting
Material: ---Al alloy, zinc alloy
Industry involved---Agricultural& Engineering& Automotive industry
Wall thickness requirements---min 2mm
Manufacturer certification---ISO9001 (2000)
We can supply die casting products with follow test reports:
Chemical composition report Tensile strength report
Key dimension checking report Full dimension report
Third-party test report
We will design each speical checking tooling to control key dimensions of aluminium die casting parts in each process. We can ensure each key dimension under control.
Why choose us?
1. Excellent and professional service:
We have a high quality sales team including sales staff, quality engineers and technicians.
2. Quality control:
The passing rate of finished product is more than 99%. Every product need to be checked by many processes.
3. Comprehensive service:
Delivery will be ready within 30 days after receiving your down payment.
We have been in this field for 20 years, covering ovearseas market of 30 different countries.
Supply all the products with good quality and competitive price.
4. Long term win-win cooperation:
A reliable supplier and reputable supplier is the key to your business. Chifine must be the best choice for you!
Die casting |
Material |
AL Al alloy,zinc alloy |
Min Tolerance | +-0.02 |
Standard |
DIN ASTM |
Weight Rang |
0.01KG~8KG |
Die casting machine |
80Ton ~800Ton |
Payment Terms T/T L/C |
Qingdao Chifine Machinery Co., Ltd is One Famous Company in China Which Specialized in Various Metal Casting Products with Over 10 Years Experience Located in Qingdao China. It Covers a Comprehensive Range of Forging, Stamping, Sand Casting, Investment Casting, Die Casting and Machining and Was Widely Used in Agriculture Machinery, Motor Vehicle, Architecture, Railway and Engineering Chifine Has Accumulated Important and Valuable Experience in Design, Manufacturing and Customer Service Over These Years We Will Continue to Integrate Our Technical Superiority, Improve Process and Quality to Increase Market Share and Create More Brilliant Future.
Automative Casting Line:
• Material: Grey iron(GG20-GG35); Ductile iron(GGG40-GGG60);
Malleable cast-iron(GTS35-10/45-06/55-04/65-02, CTW35-04/05/06/07).
• Product Size: 0-1000mm.
• Weight: 0.2kg-100kg
Resin Sand Casting
• Material: Grey iron(GG20-GG35); Ductile iron(GGG40-GGG60);
Malleable cast-iron(GTS35-10/45-06/55-04/65-02, CTW35-04/05/06/07).
Steel casting(ASTM/UNS; DIN; JIS; NF; BS; ISO)
• Product Size: 0-1500mm.
• Weight: 10kg-5000kg
Shell Mould Casting
Shell casting is one of resin sand casting process.
It is suitable for thin-wall casting parts, be free from porosity.
• Material: Grey iron(GG20-GG35); Ductile iron(GGG40-GGG60);
Malleable cast-iron(GTS35-10/45-06/55-04/65-02, CTW35-04/05/06/07).
Steel alloy; Aluminum alloy; Copper alloy.
• Product Size: 0-500mm.
• Weight: 50g-100kg.
• Wall thickness: 4-20mm
Lost Wax Casting
• Advanced wax-injection-machine and tool to ensure accurate wax-patten.
• Stable temperature and humidity environment make the wax-patten no deformation.
• Material:
Carbon steel; Stainless steel; Alloy steel.
Grey iron(GG20-GG35).
Ductile iron(GGG40-GGG60);
Malleable cast-iron
(GTS35-10/45-06/55-04/65-02, CTW35-04/05/06/07).
Aluminum alloy; Copper alloy.
• Casting size: 0-500mm.
• Casting weight: 50g-100kg
Stamping and Forging Line
• Stamping and forging equipment: 16T-300T press machine
• Automatic transport forging line
• Material: Carbon steel; Stainless steel; Alloy steel.
Aluminum alloy; Copper alloy.
Machining Shop
Our machining shop located in Qingdao, using the latest CNC equipment to provide our customer with high quality products.
• Horizontal and Vertical Machining Center
• CNC lathe and normal lathe
• CNC drilling and milling Center
• Other assistant equipment
