| Prod Model: |
OEM Stainless Steel Investment Casting |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Packaging: |
Polybag + Carton + Pallet or Case |
| Range Of Application: |
Coupling & Fittings |
| Lead Time: |
20-30 Days |
| Secondary Machining: |
Milling, Tapping, Grinding |
| Weight Range: |
0.05kg to 50kgs |
| OEM & ODM: |
100% Based on Your Drawings of Investment Casting |
| Heat Treatment: |
Annealed, Tempered, Carbonized |
| After Sales Service: |
in Time |
| Material: |
Stainless Steel |
| Casting Method: |
Thermal Gravity Casting |
| Surface Preparation: |
Polishing, Powder Coating, Painting, Electroplated |
| Molding Technics: |
Investment Casting |
Product Description
OEM Stainless Steel Investment Casting
1)Casting Process: Investment casting & lost wax casing;
2)Material Available : Stainless Steel (304, 316), Carbon Steel, Brass,;
3)Tolerance: 0.001 minimum
4)Surface Finishing Available: Polishing, Anodizing, Hard Anodizing, Galvanized, ENP, Chrome plated, Nickel Plated, Powder Coating and Painting;
5)OEM order: The parts can be made completely based on your specifications such as drawing, design, sample etc.
Applications: the parts we make are widely used in the drilling field, pneumatic actuator, valves, container trucks, windows and doors.
Why can we win trust from the extensive customers? And what is our bright spot?
I'm proud of our professional, delicated, intimate and timely service!
Order Execution Procedures
1.Studying Sample or Drawing from customer
2. Send quotation to customer
3. Make tooling/mould and first samples when customers approve our quotation and place the official order to us
4. Batch production (rough casting process + machining + surface treatment) when our samples are approved by customers
5. Do the inspection for the batch before the shipment
Our Advantages:
10 years experience in manufacturing and exporting
OEM and customs service
All the parts can be manufactured according to the drawings, samples or specific industry standard
Professional and strong engineering team guarantee high quality with reasonable and low price
Advanced-level equipments
Full material testing process and quality control system
ISO quality control
Delivery on time
Software: Pro/E, Auto CAD, Solidword, CAXA, UG, etc.
Standard: ASTM, DIN, JIS, BS, EN, SAE, GB
Various materials: Grey iron, ductile iron, bronze, aluminum alloy, stainless steel, carbon steel, brass etc.
See the other Castings, Forgings and CNC Machining & Machined parts will you get?
Various Castings
Material
Technical Process
Ductile iron castings
ASTM A 536-Gr.60-40-18, 65-45-12
Green-sand moulding
DIN-GGG40, GGG50, GGG60, GGG70
Resin-sand moulding
JIS-FCD40, FCD50, FCD60, FCD70
Lost foam cast
BS-Gr370-17,Gr420-12, Gr500-7
Shell-core cast
NF-FGS370-12, FGS400-12, FGS500-7
Electric-furnace smelting
Grey iron castings
ASTM A48-No.20,25,30,35,40,45
Green-sand moulding
ASTM A126-Class A, Class B, Class C
Resin-sand moulding
DIN-GG10, GG15, GG20, GG25, GG30
Lost foam cast
JIS-FC10, FC15, FC20, FC25, FC30, FC35
Shell-core cast
BS-Grade 150, 180, 220, 260, 300, 350
Electric-furnace smelting
NF-FGL150, FGL200, FGL250, FGL300
Carbon steel castings
ASTM A216-Cr. WCB. Cr. WCA, Gr. WCC
Soluble glass sand moulding
ASTM-415-205, 450-240, 485-275, 80-40
Resin-sand moulding
DIN-GS-C25, GS-38, GS-45, GS-52
Lost wax casting
JIS-SC410, SC450, SC480,SCC5
Lost foam cast
NF-GE230, GE280, GE320, GE370
Shell-core cast
Electric -furnace smelting
Stainless steel castings
ASTM-CF-8M,CF-8, CA-15, CA-40,316,
Soluble glass sand moulding
DIN-G-X6 CrNi18 G-X7Cr13
Resin-sand moulding
JIS-SCS13, SCS1, SCS 2, SCS 14A
Lost wax casting
BS-304 C15, 410C21, 420C29, 316
Lost foam cast
NF-Z6CND18.12M, Z6CN18.10M,Z12C13
Shell-core cast
Electric -furnace smelting
Alloy steel castings
DIN-GS-40Mn5, GS-20Mn5, GS-37MnSi5
Soluble glass sand moulding
JIS-SCMn3, SCW480, SCSiMn2,SCCrM3
Resin-sand moulding
ASTM-LCC
Lost wax casting
UNS-J02505, J13048
Lost foam cast
NF-G20M6, G35CrMo4
Shell-core cast
Electric -furnace smelting
With our headquarter and manufacturing base in QingDao---the most famous port in the north of China, QINGDAO GOLDEN TIME INDUSTRY is an excellent manufacturer of castings and machining parts for all industries.
Castings like:
1) Investment casting;
2) Sodium silicate precision casting;
3) Lost wax casting;
4) Die casting;
5) Sand casting;
These casting parts are available in various materials, such as:
1) Stainless steel;
2) Carbon steel;
3) Alloy steel;
4) Nonferrous metal and so on.
In addition to castings, QINGDAO GOLDEN TIME INDUSTRY also offers the main accessories for pneumatic and electric actuators suitable for all types of valves.
Such as:
1) Cylinder,
2) Pinion,
3) End cap,
4) Piston,
5) Indicator,
6) Limit switch box, etc)
With more than 15 years of experience all QINGDAO GOLDEN TIME INDUSTRY products have been exported and sold very well in more than 20 countries in Europe, America, Southeast Asia and East Asia.
QINGDAO GOLDEN TIME INDUSTRY always provides high-quality products at favourable prices, according to the different requirements of customer from different regions.
"The quality and credit are the life of the enterprise" is always as our motto. We are ceaseless in improving the advanced production technology and scientific management, so as to give great satisfaction to our clients in the provision of the various products and services.
At the same time, your kind advice and feedback are warmly welcomed. Our hope is to develop the business with all our friends together, resulting in mutual benefit for all of us.
