Permanent Mold Aluminum Casting

Name: Permanent Mold Aluminum Casting
Brand: china-castingforging.com
SKU: 697791412
Availability: InStock
Rating: 4.7 (45 reviews)

Price:	US $ 1-100/Ton
Trade Terms:	FOB,CFR,CIF
Min Order:	1Ton
Pay Type:	L/C,T/T,D/P,Paypal,Western Union

Contact Supplier

SYI Industrial Co., Ltd.

Showroom Product Company Profile

Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Quality Control:	Strict Inspection as Per Standard
Surface Preparation:	Polishing
Material:	Aluminum

Product Description

1), We are ISO9001: 2008 certified, BSI Kitemarked, TUV certified, SGS certified and NF certified.

2), SYI products are widely used in many fields, for example bench leg for garden furniture & auto parts etc. Readable software includes PRO/E, auto CAD, UG and solid works 2008 flow analysis. You might also get suggestions from us to help you save time.

3), Processes:
A) Sand Casting
B) Permanent Mold Casting
C) Gravity Casting

4), Material:
A) A356
B) A413
C) A354

5), Heat treatment
A) T5
B) T6

6), Various surface treatment available, such as powder coating

7), Equipment:
A) CNC machining centre
B) Various surface treatment available
C) Min. Hole dia: 1 mm
Min. Wall thickness: 4 mm
Min. Tolerance would strictly according to tolerance standard of casting
Weight of the largest cast part can up to 200Kgs

8), Inspection:
A) Foundry in-house
B) Third party inspection available upon request

9), Packing:
A) Wooden Pallet
B) Plywood Pallet
C) Steel Pallet
D) As per customers' requirements

10), Guarantee:
All of SYI casting products are guaranteed with smooth and free from sand holes, blow holes, distortion or any other defects.

11), CAD/OEM service is available.

More information is available upon receipt of your enquiry.

You will get our quick reply!

MATERIAL COMPARISON TABLE for ALUMIINUM permanent mould CASTING
China	USA		UK	France	Germany	Japan	ISO
GB	ASTM	ANSI	BS	NF	DIN	JIS	ISO
ZL101	A03560	356	\	A-S7C	G-AlSi7Mg	AC4C	AlSi7Mg
ZL101A	A13560	A356.0	\	\	\	\	AlSi7MgA
ZL102	A14130	A413	LM20	A-S13	G-AlSi12	AC3A	AlSi12
ZL104	A03600	A360	LM9	A-S9G	G-AlSi10Mg	AC4A	AlSi9Mg
ZL105	A035500	A355	LM16	\	G-AlSi5Cu	AC4D	AlSi5Cu1Mg
ZL106	A0328	328.0	LM-24	\	G-ALSI8CU3	AC4B	Al8Cu1Mg
ZL115	\	\	\	\	\	\	Al5Zn1Mg
ZL116	\	\	\	\	\	\	AlSi8MgBE
ZL201	\	\	\	A-U5GT	G-AlCu4TiMg	\	AlCu4MgTi
ZL202	A03600	A360.0	\	A-U8S	\	\	AlCu10
ZL203	A029500	295.0	\	A-U5GT	G-AlCu4Ti	\	Al-Cu4MgTi
ZL301	A05200	520.0	LM10		G-AlMg10	AC7B	AlMg10
ZL303	\	\	\	\	\	\	AlMg5Si1
ZL305	\	\	\	\	\	\	AlMg8Zn1
ZL401	\	\	\	\	\	\	AlZn11Si7
ZL402	A071200	712.2	\	A-Z5C	\	\	AlZn6Mg

About SYI Group

Specialist in Municipal, Drainage & Machinery Products & Services

SYI Group Companies have served the society for over 20 years with best Municipal, Drainage and Machinery products.

* SYI Foundry (Shanxi Yuansheng Casting & Forging Industrial Co., Ltd. ) --- manufactures Manhole Covers, Gully Gratings, Surface Boxes, Tree Gratings, Bollards, Garden Benches, Cast Lamp Posts & Bases and all types of SYI/OEM municipal products and outdoor furnitures.

* SYI Pipeline Corporation --- manufactures a full range of Pipeline products and accessories like Pipes, Fittings, Universal Couplings, Flanged Adaptors, Quick Adaptors, Dismantling Joints, Clamps, Valves, and etc.

* SYI Industrial Casting Division (Shanxi Yuansheng Industrial Co., Ltd. ) --- manufactures all kinds of Investment Castings / Precision Castings, Lost-Wax Castings, Resin Sand Casting, Lost Foam Castings and more.

* SYI Forging Factory (Shanxi Yuansheng Casting & Forging Industrial Co., Ltd. ) --- manufactures Flanges, Forged Rings, Forged Fittings, Lifting Anchors, Drop Forgings, Cold Forgings and other Free Forging and Die Forging products.

* SYI Aluminum Division --- manufactures Aluminum Sand Castings, Permanent Mould, Aluminum Die Castings, Aluminum Extrusions and all types of aluminum products.

Since the second half of 20th century, SYI has been an OEM manufacturer of machined & un-machined castings and forgings in a variety of industries. Today, we manufacture over 1, 000 products - everything from single flange to customized street lamps. SYI are continuing to refine our role as a technical expert, quality leader and fast reactor.

At Shanxi base, we have over 500, 000 square meters of workshop, warehousing and production facilities. We have 6 automatic moulding machine lines, CAD machining center, professional laboratory, in-house pattern & tooling shops and most important-a group of highly experienced and technically qualified staff.

SYI regards quality as an essential and integral part of our business success. Until now, we are ISO9001: 2008 TUV certified, BSI Kitemarked, SGS certified, UL listed, FM certified and NF certified. Manufacturing "SYI" Brand products has evolved as a mark of quality!

SYI also has the capacity to assist the customer from initial design, engineering to final sample and production.

Our aim is to provide all of our customers with VALUE of the products in stead of only low prices.
