| Prod Model: |
BM12TQ |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Forging Forming Method: |
Free Forging |
Product Description
BM12TQ (Pneumatic riveting machine)
Characteristics:
Desktop with pneumatic driven
Orbital structure
Power head adjustable
Suitable to setting on production line
Max. riveting diameter Φ12mm
Stroke speed adjustable
Pneumatic with stepless regulation
Customzied available
Scope of application: The instrument appearance, daily hardware, electrical equipment, medical equipment, automobile parts etc.
The model of BM12TQ is a kind of smaller desktop pneumatic riveting machine with orbital structure. The machine's power head adjustment up and down to meet variety of workpiece's body and shape. The pneumatic system equipped with aerosol lubricating,double way regulation to control piston stroke speed effectively. Electric control system equipped with counter and time relay to easy and simple operations. T-slot on bench to fixing clamping apparatus available, positioning hole is coaxial with spindle to insure riveting process accuracy at ±0.02mm.
Specification:
Max. riveting diameter 12mm ( solid steel rivet )
Max riveting pressure 20Kn
Stroke Length Range 30mm
Available working space 170mm
Throat depth 160mm
Riveting tool length 50mm
Angle of inclination 4°
Motive force Pneumatic
Workbench dimensions 360mm×290mm
Power 0.75Kw
Physical size 400mm×500mm×980mm
Net weight 280Kg
As a leading provider of riveting machines and equipment in China, Wuhan Rivet Machinery designs, manufactures and supports reliable and economical riveting products for the automobile, motorcycle, aerospace, hardware and architectural industries. Our company's products and tailored services include radial riveting, orbital riveting and ladder making riveting with various features and specifications.
Wuhan Rivet Machinery is a Chinese private science and technology enterprise founded in June 2002. Our global reach has expanded over the years, making us a large manufacturer and service provider for riveting machines today. In 2012, the company partnered with Wuhan University and built the only national riveting technology research lab, to develop the third generation Wheel-hub Bearing Intelligent riveting machine and CNC Turret riveting machine. Wuhan Rivet Machinery received the prestigious "High and New-tech Enterprise" award from the National Government in 2012.
We have a long tradition of innovation and quality improvement. By 2012, we completed 13 large-scale projects and obtained 11 National Patents with independent intellectual copyrights. Our Double-Cylinder pneumatic riveting machine received national funding for its contribution to environmental protection and energy conservation.
Wuhan Rivet designs and builds assembly equipment solutions with more than 100 unique styles, functions and techniques, including:
Desk Top/ Vertical/ Horizontal riveting machine
Hydraulic/ Pneumatic riveting machine
Rivetless riveting machine
Self-piercing riveting machine
CNC riveting machine
Rolling machine
Auto-feed riveting machine
Riveting production line
Special purpose riveting machine (customized): Hub-bearing, chassis
Ladder, engine cap, wiper, brake etc.
Our corporate mission statement is "Unmatched quality and credible service". It expresses our commitment to contributing to the industry and society by offering the highest product quality with free one-year warranty and extensive custom support. All Wuhan Rivet products comply with ISO9001/European CE standards and have been exported to over 50 countries and regions, including US, UK, Japan, France, Italy, Germany, India, Poland, Brazil, Argentina and Malaysia etc.
