| Prod Model: |
AF-T50 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Name: |
Rainspout Roll Forming Machinery |
| Machine Color: |
as Require |
| Machine Size: |
15m*1.2m*1.4m |
| Machine Weight: |
8t |
| Warranty: |
18months |
| Size Of Container: |
40gp |
| Usage: |
Tube |
| Life Long: |
10year |
| Control System: |
PLC |
| Cutting Type: |
Hydraulic |
| Forging Forming Method: |
Mold Forging |
Product Description
Rainspout roll forming machinery
Breif Introduction
Down pipe forming machine mainly consists of decoiler, roll forming system, cutting equipment, protective guard, hydraulic system, control system, and run out table.
Curving pipe forming machine is the complementary equipment for down pipe forming machine. It can make curve for down pipe to meet he requirements of practical engineering prefects.
Components and Functions
2.1 Standard Decoilers
For use with 1260± 5 mm wide steel coil sheet up to 5 tons in weight. The Max. Outer diameter is 1260mm, the inner diameter is 500mm or 600mm, if not in this rang, the decoiler has to be redesigned. Onsists of one uncoiler with capacity of 5000kgs and its base. The steel sheet is manually fed to the guiding equipment under the function of friction and traction
2.2 Roll Forming system
Including guiding rollers, mainframe transmission, chassis and toolings. The shape is
Made in this part. The rollers are mad of high grade ASTM 1045 forged steel, with
Digital-controlled procession, Panted with hard chrome. The active shaft material is high grade
ASTM 1045 carbon wrought steel can improve the integrated mechanic feature of the shaft
2.3 Post-cutting Equipment
The length and blocks can be set by the buyer through the control panel, when reach the set length, the machine will cut the panel automatically. The cutting is finished under the power of hydraulic station which guarantees the precision of cutting.
2.4 Hydraulic system
This part give the power to cutting equipment, make the cutting smooth. It is off without
Cutting, which can save the power.
2.5 PLC Control System
Main components imported from Mitsubishi. All language in English.
2.6 Run Out Table
The finished panel will come out to the table. Support the finished panels. The quantity we supply is 2 pieces with length 2000mm, it can support panels with 6000mm at normal condition
Working flow:
Decoiler-------- roll forming-------cutting--------output table
We mainly supply high quality roll forming machine. We have achieved good performance up to now, sincerely welcome businessmen overseas to establish a long-term cooperation to create a beautiful tomorrow!
Our factory mainly produce all kinds of roll forming machine, for example, rofo sheet roll forming machine, c purlin roll forming machine, glazed tile roll forming machine, deck floor roll forming machine, sandwich panel production line and so on.
Our factory is established form 2010, up to now, we have sold machines to Canada, Bolivia, South Africa, Dubai, India, Russia and many other countries,
Hope we can cooperate happily
