Roller Shutter Door Machine Made in China

Name: Roller Shutter Door Machine Made in China
Brand: china-castingforging.com
SKU: 679744461
Availability: InStock
Rating: 4.7 (111 reviews)

Price:	US $ 7500/Set
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Set
Pay Type:	L/C,T/T,D/P,Paypal,Money Gram

Contact Supplier

Cangzhou Dixin Roll Forming Machine Co., Ltd.

Showroom Product Company Profile

Prod Model:	DX75
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Name:	Roller Shutter Door Machine
Suitable To Process:	Color Steel Plate
Width Of The Plate:	According to Customer's Request
.Rollers:	12rows
.Dimensions:	3.51.351.51m
Power:	3+3kw
Thickness Of The Plate:	0.3-0.8mm
Diameter Of The Roller:	40mm
Weight:	About 1.5t
Control System:	PLC Control
Forging Forming Method:	Mold Forging

Product Description

Roller Shutter Door Machine made in china

Standard Color Steel Sheet Roller Shutter Door Roll Forming Machine
Glazed Tile Roll forming Machine,Color Steel Roll Forming Machine,Roofing Roll Forming
Application
This type of sheet can be widely used as the door of garage, storage and supermarket.
Quick Detail
1.Suitable to process: Color steel plate
2.Width of the plate:165mm
3.Rollers: 12rows
4.Dimensions: 3.5*1.35*1.51m
5.Power: 3+3kw
6.Thickness of the plate:0.3-0.5mm
7.Diameter of the roller:Φ38mm
8.Weight: About 1.5T
9.Processing precision: Within 1.00mm
10.Control system: PLC control

No.	Main Parameter of Roller Shutter Door Roll Forming Machine
1	Suitable to process	Color steel plate
2	Width of the plate	165mm
3	Rollers	12 rows
4	Dimensions	350013501510mm
5	Power	3+3kw
6	Thickness of the plate	0.3-0.5mm
7	Productivity	15m/min
8	Diameter of the roller	Φ70mm
9	Weight	About 1.5T
10	Voltage	380V 50Hz 3phases
11	Material of the cutting plate	Cr12
12	Hydraulic	40#
13	Processing precision	Within 1.00mm
14	Control system	PLC control

Industrial Process And Component Specification

No		Technical Specification
1	Manual Uncoiler	Usage:It is used to support the steel coil and uncoil it in a turnable way The steel coil is uncoiled by hand. Loading capacity:1.2T, Inner diameter: 500-508mm
2	Feeding Table	Put the raw material(steel plate) through the beach to manufacture and process It can guarantee that the products are neat Parallel and everything is uniformity Please refer to the equipment regulation to know the function of locate angle iron.
3	Main Roll Forming Machine	Material of rollers:45# steel,roller surfaces polishing, hard plating The polished surface and the heat treatment towards the molds also can keep the molding Plate surface smooth and not easy to be marked when it is being stamped
4	Shearing Mechanism	Flying saw cutting , Smooth surface without burr
5	Output Table	It adopts welded steel and supported roller to transmit the products,which is used to collect the finished products.

Packaging & Shipping
1.We have professional technicians for loading
Guaranteed the goods load into container without any damage.
2.Transportation : Machines need one 20 feet container to hold

Our enterprise, Cangzhou Dixin Roll Forming Machine Co., Ltd, as the professional and leading manufacturer, can manufacture, design, installation and debug various roll forming machines and metal processing sheet equipments, which produce metal roof wall panel, glazed roof tile, CZ steel purlin, floor decking, roof ridge cap, sandwich panel, roof truss, shutter panel, shutter slat, door frame, guardrail, and metal sheet uncoiler, bending, slitting, cutting, flattening, punching, crimping and sandwich panel forming machine.

We exports to most of the world. USA, UK, Africa, Russia, Indian and many other countries.

The davantage of our factoy is that

1. Many panel profile drawing machine designs available

2. Good quality machine

3. Good communication and good after sale service

In the next five years, we provide much better quality machine at reasonable price but competitive than Other supplier. So we can earn more market in the world.

Pls contact for more business.
