| Prod Model: |
AF-R1025 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Name: |
Roofing Sheet Roll Forming Machinery |
| Machine Color: |
as Require |
| Machine Size: |
6.5m*1.4m*1.4m |
| Machine Weight: |
4tons |
| Control System: |
PLC |
| Cutting Type: |
Hydraulic |
| Driven Type: |
Chain |
| Usage: |
Roof and Wall |
| Size Of Container: |
40gp |
| Life Long: |
10year |
| Forging Forming Method: |
Mold Forging |
Product Description
Roofing sheet roll forming machinery
Other machine we manufacture
Cold roll forming mahcine, color steel roll forming machine, roof and wall panel machine, decking floor roll forming machine, floor decing forming mahcine, stud and track roll forming machine, Z and C purlin machine, highway guardrail roll forming machine, cable tray machine, and so on.
Working flow:
Decoiler----- feeding ------roll forming ------ cutting----output table
Machine components:
De-coiler------------------------------------------1set
Forming machine------------------------------1set
Cutting device -----------------------------------1set
Punching device---------------------------------1set
PLC control box ---------------------------------1set
Hydraulic pump station------------------------1set
Production support table----------------------1set
Techincal description:
1)Decoiler
Maual type: 5T
Inner Diameter: Φ 450 Φ 600 mm
Out Diameter: 1500 mm
2)Roll forming machine
Material thickness: 0.3--0.8mm
Effctive width: 840mm
Feeding width: 1000mm(adjustable as differnent profile drawing)
Roller steps: 13
Out diameter of shaft: 70mm
Material of shaft: 45#steel adjustable treatment
Material of Roller: 45# steel with chromizing on surface
Thickness of chain: 6''
Main frame: 300 H steel
Main line speed: 8-12m/min
3)Cutting device
Hydraulic cutter:
Cutting tool material: Cr12, Heat treatment
4)Output table
It is simple and used to load finished product.
Length: 6m
5) Control system
Type: PLC Frequency Control System with touch screen
PLC Brand: Japan Panasonic
Encoder Brand: Omron
Length Error: ± 2mm
Transducer: Panasonic
Contact person: Arno Hao
Tel: 86-21-67298619
Mobile: 86-18717894416
|
Terms |
|
Payment type |
35% T/T prepaid and balance should be paid before loading |
|
Delivery time |
30days after receving advance payment |
|
Guarantee period |
18monthes free service/ pay service all the machine life |
|
Installation and training |
If buyers visit our factory and check the machine,
we will teach you how to install and use the machine,
and also train your workers/technician face to face.
Without visiting, we will send you user manual and
video to teach you to install and operate.
If buyer needs our technician to go to your local factory,
please arrange board and lodging and other necessary things. |
We mainly supply high quality roll forming machine. We have achieved good performance up to now, sincerely welcome businessmen overseas to establish a long-term cooperation to create a beautiful tomorrow!
Our factory mainly produce all kinds of roll forming machine, for example, rofo sheet roll forming machine, c purlin roll forming machine, glazed tile roll forming machine, deck floor roll forming machine, sandwich panel production line and so on.
Our factory is established form 2010, up to now, we have sold machines to Canada, Bolivia, South Africa, Dubai, India, Russia and many other countries,
Hope we can cooperate happily
