Round Bar Steel [20mncr5] Alloy Steel Forgings Alloy Steel Round Bars

Round Bar Steel [20mncr5] Alloy Steel Forgings Alloy Steel Round Bars
Price: US $ 825/Ton
Trade Terms: FOB,CFR,CIF
Min Order: 10/Ton
Pay Type: L/C,T/T,D/P
Prod Model: [20mncr5]
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Ultrasonic Test: Sep1921-84 Class C/C, D/D
Materials: 20mncr5
Place Of Origin: Wuxi,China
Rang Of Size: 130mm-1200mm
Tolerance: -0/+2mm for Size and -0/+10mm for Length
Range Of Length: Customized
Weight Of Per Bar: by Request
Delivery Condition: Optional
Property: by Specifications of Customers
Payment: Tt or LC
Type: Alloy Steel Bar
Standard: BS
Technique: Forged
Application: Shipbuilding Industry
Alloy: Alloy
Special Use: Cold Heading Steel
Surface Treatment: Shipbuilding Industry

Product Description

Steel Grade: 20MnCr5
Grade:20MnCr5
Process: Forged from vacuum degassed ingots.
Chemical composition:
CSiMnPSCrNiMoCuAlV

0.17/0.22

0.15/0.35

1.0/1.4

<=0.03

<=0.03

1.0/1.3

<=0.1

<=0.03

<=0.3

0.02/0.05

<=0.05

Material:20MnCr5  forged steel round bar
Process:Forged from vacuum degassed ingots.
Diameter:120mm-1000mm (optional)
Length:1000mm-12000mm Straightness: 3mm/M max(optional)
Process:EAF + LF + VD + Forged + Heat Treatment (optional)
Delivery condition:Hot forged +Rough machined (black surface after Q/T)+ Turned (optional)
Delivery Time:30-45 days
MOQ:20 tons
Heat treatment:Normalized / Annealed / Quenched / tempered
Technical Data:According to the customer's requirement of Chemical Composition, Physical Properties and Mechanical Testing
Properties:Yield=310 Mpa Minimum; Tensile=600 Mpa minimum; %EI=13min,Surface Hardness=BHN160-220(As your request)
Test:Ultrasonic test according to SEP 1921-84  Class C/c and D/d  (optional)
Marking:Grade, heat NO. length will be stamped one each bar with required color
Payment:30% advance by T\T; Balance pay before the shipment against shipping documents or irrevocable LC at sight
similar steel grade20CrMnTi/20CrMnS5/30CrMnTi
Application:Statically and dynamically stressed components for vehicles, engines and machines. For parts of larger cross-sections, crankshafts, gears.
